Specifications: BMW 1 Series Hatchback 5dr (F20 LCI, facelift 2017) 118d (150 Hp) 2017, 2018, 2019

2017 BMW 1 Series Hatchback 5dr (F20 LCI, facelift 2017) - Photo 1

BMW 1 Series Hatchback 5dr (F20 LCI, facelift 2017) 118d (150 Hp) – Full specifications
General information
Brand BMW
Model 1 Series
Generation 1 Series Hatchback 5dr (F20 LCI, facelift 2017)
Modification (Engine) 118d (150 Hp)
Start of production 2017 year
End of production 2019 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 4.8-5.2 l/100 km
49 – 45.2 US mpg
58.9 – 54.3 UK mpg
20.8 – 19.2 km/l
Fuel consumption (economy) – extra urban 3.5-3.8 l/100 km
67.2 – 61.9 US mpg
80.7 – 74.3 UK mpg
28.6 – 26.3 km/l
Fuel consumption (economy) – combined 4.0-4.3 l/100 km
58.8 – 54.7 US mpg
70.6 – 65.7 UK mpg
25 – 23.3 km/l
CO2 emissions 109-114 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 8.3 sec
Acceleration 0 – 62 mph 8.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.9 sec
Maximum speed 212 km/h
131.73 mph
Emission standard Euro 6
Weight-to-power ratio 9 kg/Hp, 111.1 Hp/tonne
Weight-to-torque ratio 4.2 kg/Nm, 237 Nm/tonne
Engine specs
Power 150 Hp @ 4000 rpm.
Power per litre 75.2 Hp/l
Torque 320 Nm @ 1500-3000 rpm.
236.02 lb.-ft. @ 1500-3000 rpm.
Engine layout Front, Longitudinal
Engine Model/Code B47D20A
Engine displacement 1995 cm3
121.74 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 84 mm
3.31 in.
Piston Stroke 90 mm
3.54 in.
Compression ratio 16.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Twin-power turbo, Intercooler
Engine oil capacity 5 l
5.28 US qt | 4.4 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7 l
7.4 US qt | 6.16 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1350 kg
2976.24 lbs.
Max. weight 1915 kg
4221.85 lbs.
Max load 565 kg
1245.61 lbs.
Trunk (boot) space – minimum 360 l
12.71 cu. ft.
Trunk (boot) space – maximum 1200 l
42.38 cu. ft.
Fuel tank capacity 52 l
13.74 US gal | 11.44 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 690 kg
1521.19 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4329 mm
170.43 in.
Width 1765 mm
69.49 in.
Width including mirrors 1984 mm
78.11 in.
Height 1421 mm
55.94 in.
Wheelbase 2690 mm
105.91 in.
Front track 1535 mm
60.43 in.
Rear (Back) track 1569 mm
61.77 in.
Front overhang 770 mm
30.31 in.
Rear overhang 869 mm
34.21 in.
Ride height (ground clearance) 140 mm
5.51 in.
Drag coefficient (Cd) 0.30
Minimum turning circle (turning diameter) 10.9 m
35.76 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Double wishbone
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 195/55 R16; 205/55 R16; 205/50 R17; 225/45 R17; 245/40 R17; 225/40 R18; 245/35 R18
Wheel rims size 6.5J x 16; 7J x 16; 7J x 17; 7.5J x 17; 8J x 17; 7.5J x 18; 8J x 18
