Specifications: BMW 1 Series Hatchback 5dr (F20 LCI, facelift 2017) 120i (184 Hp) 2017, 2018, 2019

2017 BMW 1 Series Hatchback 5dr (F20 LCI, facelift 2017) - Photo 1

BMW 1 Series Hatchback 5dr (F20 LCI, facelift 2017) 120i (184 Hp) – Full specifications
General information
Brand BMW
Model 1 Series
Generation 1 Series Hatchback 5dr (F20 LCI, facelift 2017)
Modification (Engine) 120i (184 Hp)
Start of production 2017 year
End of production 2019 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 7.6-8.1 l/100 km
30.9 – 29 US mpg
37.2 – 34.9 UK mpg
13.2 – 12.3 km/l
Fuel consumption (economy) – extra urban 4.7-5.0 l/100 km
50 – 47 US mpg
60.1 – 56.5 UK mpg
21.3 – 20 km/l
Fuel consumption (economy) – combined 5.7-6.1 l/100 km
41.3 – 38.6 US mpg
49.6 – 46.3 UK mpg
17.5 – 16.4 km/l
CO2 emissions 131-140 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 7.1 sec
Acceleration 0 – 62 mph 7.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6.7 sec
Maximum speed 230 km/h
142.92 mph
Emission standard Euro 6
Weight-to-power ratio 7.4 kg/Hp, 134.3 Hp/tonne
Weight-to-torque ratio 4.7 kg/Nm, 211.7 Nm/tonne
Engine specs
Power 184 Hp @ 5000 rpm.
Power per litre 92.1 Hp/l
Torque 290 Nm @ 1350-4250 rpm.
213.89 lb.-ft. @ 1350-4250 rpm.
Engine layout Front, Longitudinal
Engine Model/Code B48B20A
Engine displacement 1998 cm3
121.93 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82 mm
3.23 in.
Piston Stroke 94.6 mm
3.72 in.
Compression ratio 11:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Twin-power turbo, Intercooler
Engine oil capacity 5.25 l
5.55 US qt | 4.62 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.8 l
8.24 US qt | 6.86 UK qt

Space, Volume and weights
Kerb Weight 1370 kg
3020.33 lbs.
Max. weight 1930 kg
4254.92 lbs.
Max load 560 kg
1234.59 lbs.
Trunk (boot) space – minimum 360 l
12.71 cu. ft.
Trunk (boot) space – maximum 1200 l
42.38 cu. ft.
Fuel tank capacity 52 l
13.74 US gal | 11.44 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 670 kg
1477.1 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4329 mm
170.43 in.
Width 1765 mm
69.49 in.
Width including mirrors 1984 mm
78.11 in.
Height 1421 mm
55.94 in.
Wheelbase 2690 mm
105.91 in.
Front track 1535 mm
60.43 in.
Rear (Back) track 1569 mm
61.77 in.
Front overhang 770 mm
30.31 in.
Rear overhang 869 mm
34.21 in.
Ride height (ground clearance) 140 mm
5.51 in.
Drag coefficient (Cd) 0.31
Minimum turning circle (turning diameter) 10.9 m
35.76 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Double wishbone
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 195/55 R16; 205/55 R16; 205/50 R17; 225/45 R17; 245/40 R17; 225/40 R18; 245/35 R18
Wheel rims size 6.5J x 16; 7J x 16; 7J x 17; 7.5J x 17; 8J x 17; 7.5J x 18; 8J x 18
