Specifications: BMW 1 Series Hatchback (F70) 120 (204 Hp) Steptronic DCT 2024, 2025

2025 BMW 1 Series Hatchback (F70) - Photo 1

BMW 1 Series Hatchback (F70) 120 (204 Hp) Steptronic DCT – Full specifications
General information
Brand BMW
Model 1 Series
Generation 1 Series Hatchback (F70)
Modification (Engine) 120 (204 Hp) Steptronic DCT
Start of production 2024 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – combined (NEDC) 6.7 l/100 km
35.1 US mpg
42.2 UK mpg
14.9 km/l
CO2 emissions (NEDC) 153 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 7.2 sec
Acceleration 0 – 62 mph 7.2 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6.8 sec
Maximum speed 246 km/h
152.86 mph
Weight-to-power ratio 7 kg/Hp, 143.2 Hp/tonne
Weight-to-torque ratio 4.8 kg/Nm, 210.5 Nm/tonne
Engine specs
Power 204 Hp @ 5000-6500 rpm.
Power per litre 102.1 Hp/l
Torque 300 Nm @ 1450-4500 rpm.
221.27 lb.-ft. @ 1450-4500 rpm.
Engine layout Front, Transverse
Engine Model/Code B48
Engine displacement 1998 cm3
121.93 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82 mm
3.23 in.
Piston Stroke 94.6 mm
3.72 in.
Number of valves per cylinder 4
Fuel injection system Direct injection and Multi-port manifold injection
Engine aspiration Twin-scroll turbo, Intercooler
Valvetrain VALVETRONIC, Double VANOS
Engine oil specification Log in to see.Log in to see.
Engine systems Start & Stop System

Space, Volume and weights
Kerb Weight 1425 kg
3141.59 lbs.
Max. weight 2000 kg
4409.25 lbs.
Max load 575 kg
1267.66 lbs.
Trunk (boot) space – minimum 380 l
13.42 cu. ft.
Trunk (boot) space – maximum 1200 l
42.38 cu. ft.
Fuel tank capacity 49 l
12.94 US gal | 10.78 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (12%) 1300 kg
2866.01 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4361 mm
171.69 in.
Width 1800 mm
70.87 in.
Width including mirrors 2072 mm
81.57 in.
Height 1459 mm
57.44 in.
Wheelbase 2670 mm
105.12 in.
Front overhang 899 mm
35.39 in.
Rear overhang 792 mm
31.18 in.
Ride height (ground clearance) 156 mm
6.14 in.
Minimum turning circle (turning diameter) 11.7 m
38.39 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 7 gears, automatic transmission Steptronic DCT
Front suspension Spring Strut, Transverse stabilizer
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/55 R17
Wheel rims size 7.5J x 17
