Specifications: BMW 3 Series Gran Turismo (F34 LCI, Facelift 2016) 318d (150 Hp) 2016, 2017, 2018, 2019, 2020

2016 BMW 3 Series Gran Turismo (F34 LCI, Facelift 2016) - Photo 1

BMW 3 Series Gran Turismo (F34 LCI, Facelift 2016) 318d (150 Hp) – Full specifications
General information
Brand BMW
Model 3 Series
Generation 3 Series Gran Turismo (F34 LCI, Facelift 2016)
Modification (Engine) 318d (150 Hp)
Start of production 2016 year
End of production 2020 year
Powertrain Architecture Internal Combustion engine
Body type Grand Tourer
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 5.6-5.3 l/100 km
42 – 44.4 US mpg
50.4 – 53.3 UK mpg
17.9 – 18.9 km/l
Fuel consumption (economy) – extra urban 4.1-4.0 l/100 km
57.4 – 58.8 US mpg
68.9 – 70.6 UK mpg
24.4 – 25 km/l
Fuel consumption (economy) – combined 4.7-4.5 l/100 km
50 – 52.3 US mpg
60.1 – 62.8 UK mpg
21.3 – 22.2 km/l
CO2 emissions 123-117 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 9.3 sec
Acceleration 0 – 62 mph 9.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.8 sec
Maximum speed 210 km/h
130.49 mph
Emission standard Euro 6
Weight-to-power ratio 10.5 kg/Hp, 95.5 Hp/tonne
Weight-to-torque ratio 4.9 kg/Nm, 203.8 Nm/tonne
Engine specs
Power 150 Hp @ 4000 rpm.
Power per litre 75.2 Hp/l
Torque 320 Nm @ 1500-3000 rpm.
236.02 lb.-ft. @ 1500-3000 rpm.
Engine layout Front, Longitudinal
Engine Model/Code B47D20A
Engine displacement 1995 cm3
121.74 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 84 mm
3.31 in.
Piston Stroke 90 mm
3.54 in.
Compression ratio 16.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Twin-power turbo, Intercooler
Engine oil capacity 5 l
5.28 US qt | 4.4 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7 l
7.4 US qt | 6.16 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1570 kg
3461.26 lbs.
Max. weight 2140 kg
4717.89 lbs.
Max load 570 kg
1256.63 lbs.
Trunk (boot) space – minimum 520 l
18.36 cu. ft.
Trunk (boot) space – maximum 1600 l
56.5 cu. ft.
Fuel tank capacity 57 l
15.06 US gal | 12.54 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (12%) 1600 kg
3527.4 lbs.
Permitted trailer load without brakes 745 kg
1642.44 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4824 mm
189.92 in.
Width 1828 mm
71.97 in.
Height 1508 mm
59.37 in.
Wheelbase 2920 mm
114.96 in.
Front track 1541 mm
60.67 in.
Rear (Back) track 1586 mm
62.44 in.
Ride height (ground clearance) 165 mm
6.5 in.
Drag coefficient (Cd) 0.28
Minimum turning circle (turning diameter) 11.8 m
38.71 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Double wishbone
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/55 R17 97V
Wheel rims size 8.0J x 17
