Specifications: BMW 3 Series Touring (F31 LCI, Facelift 2015) 318d (150 Hp) xDrive 2015, 2016, 2017, 2018, 2019

2015 BMW 3 Series Touring (F31 LCI, Facelift 2015) - Photo 1

BMW 3 Series Touring (F31 LCI, Facelift 2015) 318d (150 Hp) xDrive – Full specifications
General information
Brand BMW
Model 3 Series
Generation 3 Series Touring (F31 LCI, Facelift 2015)
Modification (Engine) 318d (150 Hp) xDrive
Start of production 2015 year
End of production 2019 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 6.2-5.7 l/100 km
37.9 – 41.3 US mpg
45.6 – 49.6 UK mpg
16.1 – 17.5 km/l
Fuel consumption (economy) – extra urban 4.4-4.1 l/100 km
53.5 – 57.4 US mpg
64.2 – 68.9 UK mpg
22.7 – 24.4 km/l
Fuel consumption (economy) – combined 5.1-4.7 l/100 km
46.1 – 50 US mpg
55.4 – 60.1 UK mpg
19.6 – 21.3 km/l
CO2 emissions 133-123 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 9.2 sec
Acceleration 0 – 62 mph 9.2 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.7 sec
Maximum speed 206 km/h
128 mph
Emission standard Euro 6
Weight-to-power ratio 10.5 kg/Hp, 95.5 Hp/tonne
Weight-to-torque ratio 4.9 kg/Nm, 203.8 Nm/tonne
Engine specs
Power 150 Hp @ 4000 rpm.
Power per litre 75.2 Hp/l
Torque 320 Nm @ 1500-3000 rpm.
236.02 lb.-ft. @ 1500-3000 rpm.
Engine layout Front, Longitudinal
Engine Model/Code B47D20A
Engine displacement 1995 cm3
121.74 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 84 mm
3.31 in.
Piston Stroke 90 mm
3.54 in.
Compression ratio 16.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Twin-power turbo, Intercooler
Engine oil capacity 5 l
5.28 US qt | 4.4 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7 l
7.4 US qt | 6.16 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1570 kg
3461.26 lbs.
Max. weight 2145 kg
4728.92 lbs.
Max load 575 kg
1267.66 lbs.
Trunk (boot) space – minimum 495 l
17.48 cu. ft.
Trunk (boot) space – maximum 1500 l
52.97 cu. ft.
Fuel tank capacity 57 l
15.06 US gal | 12.54 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (12%) 1600 kg
3527.4 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4633 mm
182.4 in.
Width 1811 mm
71.3 in.
Height 1434 mm
56.46 in.
Wheelbase 2810 mm
110.63 in.
Front track 1542 mm
60.71 in.
Rear (Back) track 1582 mm
62.28 in.
Ride height (ground clearance) 145 mm
5.71 in.
Drag coefficient (Cd) 0.30
Minimum turning circle (turning diameter) 11.7 m
38.39 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent coil spring
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/60 R16 92W
Wheel rims size 7.0J x 16
