Specifications: BMW 3 Series Touring (G21) 330d (265 Hp) xDrive Steptronic 2019, 2020

2019 BMW 3 Series Touring (G21) - Photo 1

BMW 3 Series Touring (G21) 330d (265 Hp) xDrive Steptronic – Full specifications
General information
Brand BMW
Model 3 Series
Generation 3 Series Touring (G21)
Modification (Engine) 330d (265 Hp) xDrive Steptronic
Start of production June, 2019 year
End of production 2020 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 6.4-6.5 l/100 km
36.8 – 36.2 US mpg
44.1 – 43.5 UK mpg
15.6 – 15.4 km/l
Fuel consumption (economy) – extra urban 4.7-5.1 l/100 km
50 – 46.1 US mpg
60.1 – 55.4 UK mpg
21.3 – 19.6 km/l
Fuel consumption (economy) – combined 5.4-5.6 l/100 km
43.6 – 42 US mpg
52.3 – 50.4 UK mpg
18.5 – 17.9 km/l
CO2 emissions 140-146 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 5.4 sec
Acceleration 0 – 62 mph 5.4 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 5.1 sec
Maximum speed 250 km/h
155.34 mph
Emission standard Euro 6d – TEMP
Weight-to-power ratio 6.6 kg/Hp, 151.9 Hp/tonne
Weight-to-torque ratio 3 kg/Nm, 332.4 Nm/tonne
Engine specs
Power 265 Hp @ 4000 rpm.
Power per litre 88.5 Hp/l
Torque 580 Nm @ 1750-2750 rpm.
427.79 lb.-ft. @ 1750-2750 rpm.
Engine layout Front, Longitudinal
Engine Model/Code B57D30A
Engine displacement 2993 cm3
182.64 cu. in.
Number of cylinders 6
Engine configuration Inline
Cylinder Bore 84 mm
3.31 in.
Piston Stroke 90 mm
3.54 in.
Compression ratio 16.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Twin-power turbo, Intercooler
Engine oil capacity 6.5 l
6.87 US qt | 5.72 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8 l
8.45 US qt | 7.04 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1745 kg
3847.07 lbs.
Max. weight 2350 kg
5180.86 lbs.
Max load 605 kg
1333.8 lbs.
Trunk (boot) space – minimum 500 l
17.66 cu. ft.
Trunk (boot) space – maximum 1510 l
53.33 cu. ft.
Fuel tank capacity 59 l
15.59 US gal | 12.98 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (12%) 1800 kg
3968.32 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4709 mm
185.39 in.
Width 1827 mm
71.93 in.
Width including mirrors 2068 mm
81.42 in.
Height 1445 mm
56.89 in.
Wheelbase 2851 mm
112.24 in.
Front track 1573 mm
61.93 in.
Rear (Back) track 1567 mm
61.69 in.
Front overhang 799 mm
31.46 in.
Rear overhang 1059 mm
41.69 in.
Ride height (ground clearance) 135 mm
5.31 in.
Drag coefficient (Cd) 0.27
Minimum turning circle (turning diameter) 12.0 m
39.37 ft.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 8 gears, automatic transmission Steptronic
Front suspension Independent coil spring
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/50 R17 98Y XL
Wheel rims size 7.5J x 17
