Specifications: BMW 5 Series Sedan (F10) 530i (272 Hp) 2011, 2012, 2013

2010 BMW 5 Series Sedan (F10) - Photo 1

BMW 5 Series Sedan (F10) 530i (272 Hp) – Full specifications
General information
Brand BMW
Model 5 Series
Generation 5 Series Sedan (F10)
Modification (Engine) 530i (272 Hp)
Start of production 2011 year
End of production 2013 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 10.2-10.4 l/100 km
23.1 – 22.6 US mpg
27.7 – 27.2 UK mpg
9.8 – 9.6 km/l
Fuel consumption (economy) – extra urban 6.1-6.3 l/100 km
38.6 – 37.3 US mpg
46.3 – 44.8 UK mpg
16.4 – 15.9 km/l
Fuel consumption (economy) – combined 7.6-7.8 l/100 km
30.9 – 30.2 US mpg
37.2 – 36.2 UK mpg
13.2 – 12.8 km/l
CO2 emissions 177-182 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 6.5 sec
Acceleration 0 – 62 mph 6.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6.2 sec
Maximum speed 250 km/h
155.34 mph
Emission standard Euro 5
Weight-to-power ratio 6 kg/Hp, 166.4 Hp/tonne
Weight-to-torque ratio 5.3 kg/Nm, 189.6 Nm/tonne
Engine specs
Power 272 Hp @ 6100 rpm.
Power per litre 90.8 Hp/l
Torque 310 Nm @ 1600-4250 rpm.
228.64 lb.-ft. @ 1600-4250 rpm.
Engine layout Front, Longitudinal
Engine Model/Code N53B30A
Engine displacement 2996 cm3
182.83 cu. in.
Number of cylinders 6
Engine configuration Inline
Cylinder Bore 85 mm
3.35 in.
Piston Stroke 88 mm
3.46 in.
Compression ratio 12:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Naturally aspirated engine
Engine oil capacity 6.5 l
6.87 US qt | 5.72 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8 l
8.45 US qt | 7.04 UK qt

Space, Volume and weights
Kerb Weight 1635 kg
3604.56 lbs.
Max. weight 2245 kg
4949.38 lbs.
Max load 610 kg
1344.82 lbs.
Trunk (boot) space – minimum 520 l
18.36 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 2000 kg
4409.25 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 90 kg
198.42 lbs.
Dimensions
Length 4899 mm
192.87 in.
Width 1860 mm
73.23 in.
Height 1464 mm
57.64 in.
Wheelbase 2968 mm
116.85 in.
Front track 1600 mm
62.99 in.
Rear (Back) track 1627 mm
64.06 in.
Ride height (ground clearance) 141 mm
5.55 in.
Drag coefficient (Cd) 0.28
Minimum turning circle (turning diameter) 11.95 m
39.21 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Double wishbone
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/55 R17; 245/45 R18; 275/40 R18; 245/40 R19; 275/35 R19; 245/35 R20; 275/30 R20
Wheel rims size 8J x 17; 8J x 18; 9J x 18; 8.5J x 19; 9J x 19; 8.5J x 20; 9J x 20
