Specifications: BMW 5 Series Sedan (G30) 525d (231 Hp) Steptronic 2017, 2018, 2019, 2020

2017 BMW 5 Series Sedan (G30) - Photo 1

BMW 5 Series Sedan (G30) 525d (231 Hp) Steptronic – Full specifications
General information
Brand BMW
Model 5 Series
Generation 5 Series Sedan (G30)
Modification (Engine) 525d (231 Hp) Steptronic
Start of production 2017 year
End of production 2020 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 5.1-5.5 l/100 km
46.1 – 42.8 US mpg
55.4 – 51.4 UK mpg
19.6 – 18.2 km/l
Fuel consumption (economy) – extra urban 4.0-4.5 l/100 km
58.8 – 52.3 US mpg
70.6 – 62.8 UK mpg
25 – 22.2 km/l
Fuel consumption (economy) – combined 4.4-4.8 l/100 km
53.5 – 49 US mpg
64.2 – 58.9 UK mpg
22.7 – 20.8 km/l
CO2 emissions 116-126 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 6.6 sec
Acceleration 0 – 62 mph 6.6 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6.3 sec
Maximum speed 250 km/h
155.34 mph
Emission standard Euro 6
Weight-to-power ratio 7 kg/Hp, 143.5 Hp/tonne
Weight-to-torque ratio 3.2 kg/Nm, 310.6 Nm/tonne
Engine specs
Power 231 Hp @ 4400 rpm.
Power per litre 115.8 Hp/l
Torque 500 Nm @ 2000 rpm.
368.78 lb.-ft. @ 2000 rpm.
Engine layout Front, Longitudinal
Engine Model/Code B47D20B
Engine displacement 1995 cm3
121.74 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 84 mm
3.31 in.
Piston Stroke 90 mm
3.54 in.
Compression ratio 16.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Twin-power turbo, Intercooler
Engine oil capacity 5.5 l
5.81 US qt | 4.84 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 11.5 l
12.15 US qt | 10.12 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1610 kg
3549.44 lbs.
Max. weight 2295 kg
5059.61 lbs.
Max load 685 kg
1510.17 lbs.
Trunk (boot) space – minimum 530 l
18.72 cu. ft.
Fuel tank capacity 66 l
17.44 US gal | 14.52 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 2000 kg
4409.25 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 90 kg
198.42 lbs.
Dimensions
Length 4936 mm
194.33 in.
Width 1868 mm
73.54 in.
Height 1479 mm
58.23 in.
Wheelbase 2975 mm
117.13 in.
Front track 1605 mm
63.19 in.
Rear (Back) track 1630 mm
64.17 in.
Ride height (ground clearance) 144 mm
5.67 in.
Drag coefficient (Cd) 0.24
Minimum turning circle (turning diameter) 12.05 m
39.53 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 8 gears, automatic transmission Steptronic
Front suspension Double wishbone
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/55 R17; 245/45 R18; 275/40 R18; 245/40 R19; 275/35 R19; 245/35 R20; 275/30 R20
Wheel rims size 7.5J x 17; 8J x 18; 9J x 18; 8J x 19; 9J x 19; 8J x 20; 9J x 20
