| General information | |
|---|---|
| Brand | BMW |
| Model | 5 Series |
| Generation | 5 Series Touring (E39) |
| Modification (Engine) | 530d (184 Hp) |
| Start of production | 1998 year |
| End of production | 2000 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate) |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 10 l/100 km 23.5 US mpg 28.2 UK mpg 10 km/l |
| Fuel consumption (economy) – extra urban | 5.9 l/100 km 39.9 US mpg 47.9 UK mpg 16.9 km/l |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 8.3 sec |
| Acceleration 0 – 62 mph | 8.3 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 7.9 sec |
| Maximum speed | 222 km/h 137.94 mph |
| Engine specs | |
| Power | 184 Hp @ 4000 rpm. |
| Power per litre | 62.9 Hp/l |
| Torque | 390 Nm @ 1750-3200 rpm. 287.65 lb.-ft. @ 1750-3200 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | M57D30 |
| Engine displacement | 2926 cm3 178.56 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | Inline |
| Cylinder Bore | 84 mm 3.31 in. |
| Piston Stroke | 88 mm 3.46 in. |
| Compression ratio | 18:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 6.5 l 6.87 US qt | 5.72 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 9.2 l 9.72 US qt | 8.09 UK qt |
|
|
|
| Space, Volume and weights | |
| Max. weight | 2310 kg 5092.68 lbs. |
| Trunk (boot) space – minimum | 410 l 14.48 cu. ft. |
| Trunk (boot) space – maximum | 1525 l 53.85 cu. ft. |
| Fuel tank capacity | 70 l 18.49 US gal | 15.4 UK gal |
| Dimensions | |
| Length | 4805 mm 189.17 in. |
| Width | 1800 mm 70.87 in. |
| Height | 1440 mm 56.69 in. |
| Wheelbase | 2830 mm 111.42 in. |
| Front track | 1512 mm 59.53 in. |
| Rear (Back) track | 1522 mm 59.92 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Wishbone |
| Rear suspension | Inclined Lever |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 225/65 R15 W |
| Wheel rims size | 15 |
