Specifications: BMW 5 Series Touring (G31) 520d (190 Hp) 2017, 2018, 2019, 2020

2017 BMW 5 Series Touring (G31) - Photo 1

BMW 5 Series Touring (G31) 520d (190 Hp) – Full specifications
General information
Brand BMW
Model 5 Series
Generation 5 Series Touring (G31)
Modification (Engine) 520d (190 Hp)
Start of production 2017 year
End of production 2020 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 5.2-5.6 l/100 km
45.2 – 42 US mpg
54.3 – 50.4 UK mpg
19.2 – 17.9 km/l
Fuel consumption (economy) – extra urban 4.1-4.6 l/100 km
57.4 – 51.1 US mpg
68.9 – 61.4 UK mpg
24.4 – 21.7 km/l
Fuel consumption (economy) – combined 4.5-4.9 l/100 km
52.3 – 48 US mpg
62.8 – 57.6 UK mpg
22.2 – 20.4 km/l
CO2 emissions 119-129 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 8 sec
Acceleration 0 – 62 mph 8 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.6 sec
Maximum speed 230 km/h
142.92 mph
Emission standard Euro 6
Weight-to-power ratio 8.7 kg/Hp, 114.8 Hp/tonne
Weight-to-torque ratio 4.1 kg/Nm, 241.7 Nm/tonne
Engine specs
Power 190 Hp @ 4000 rpm.
Power per litre 95.2 Hp/l
Torque 400 Nm @ 1750-2500 rpm.
295.02 lb.-ft. @ 1750-2500 rpm.
Engine layout Front, Longitudinal
Engine Model/Code B47D20B
Engine displacement 1995 cm3
121.74 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 84 mm
3.31 in.
Piston Stroke 90 mm
3.54 in.
Compression ratio 16.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Twin-power turbo, Intercooler
Engine oil capacity 5 l
5.28 US qt | 4.4 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8.8 l
9.3 US qt | 7.74 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1655 kg
3648.65 lbs.
Max. weight 2380 kg
5247 lbs.
Max load 725 kg
1598.35 lbs.
Trunk (boot) space – minimum 570 l
20.13 cu. ft.
Trunk (boot) space – maximum 1700 l
60.03 cu. ft.
Fuel tank capacity 66 l
17.44 US gal | 14.52 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 2000 kg
4409.25 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 90 kg
198.42 lbs.
Dimensions
Length 4942 mm
194.57 in.
Width 1868 mm
73.54 in.
Width including mirrors 2126 mm
83.7 in.
Height 1464-1498 mm
57.64 – 58.98 in.
Wheelbase 2975 mm
117.13 in.
Front track 1605 mm
63.19 in.
Rear (Back) track 1630 mm
64.17 in.
Front overhang 862 mm
33.94 in.
Rear overhang 1105 mm
43.5 in.
Ride height (ground clearance) 140 mm
5.51 in.
Drag coefficient (Cd) 0.28
Minimum turning circle (turning diameter) 12.05 m
39.53 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Double wishbone
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/55 R17; 245/45 R18; 275/40 R18; 245/40 R19; 275/35 R19; 245/35 R20; 275/30 R20
Wheel rims size 7.5J x 17; 8J x 18; 9J x 18; 8J x 19; 9J x 19; 8J x 20; 9J x 20
