Specifications: BMW 5 Series Touring (G31 LCI, facelift 2020) 520d (190 Hp) Mild Hybrid xDrive Steptronic 2020, 2021, 2022, 2023, 2024

2021 BMW 5 Series Touring (G31 LCI, facelift 2020) - Photo 1

BMW 5 Series Touring (G31 LCI, facelift 2020) 520d (190 Hp) Mild Hybrid xDrive Steptronic – Full specifications
General information
Brand BMW
Model 5 Series
Generation 5 Series Touring (G31 LCI, facelift 2020)
Modification (Engine) 520d (190 Hp) Mild Hybrid xDrive Steptronic
Start of production July, 2020 year
End of production February, 2024 year
Powertrain Architecture MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV)
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 5.2-5.4 l/100 km
45.2 – 43.6 US mpg
54.3 – 52.3 UK mpg
19.2 – 18.5 km/l
Fuel consumption (economy) – extra urban 4.2-4.3 l/100 km
56 – 54.7 US mpg
67.3 – 65.7 UK mpg
23.8 – 23.3 km/l
Fuel consumption (economy) – combined 4.6-4.7 l/100 km
51.1 – 50 US mpg
61.4 – 60.1 UK mpg
21.7 – 21.3 km/l
CO2 emissions 120-124 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 7.6 sec
Acceleration 0 – 62 mph 7.6 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.2 sec
Maximum speed 222 km/h
137.94 mph
Emission standard EURO 6d
Weight-to-power ratio 9.7 kg/Hp, 103.3 Hp/tonne
Weight-to-torque ratio 4.6 kg/Nm, 217.4 Nm/tonne
Electric cars and hybrids specs
Gross battery capacity 0.528 kWh
Electric motor 1
Electric motor power 11 Hp
Internal combustion engine specs
Power 190 Hp @ 4000 rpm.
Power per litre 95.2 Hp/l
Torque 400 Nm @ 1750-2500 rpm.
295.02 lb.-ft. @ 1750-2500 rpm.
Engine layout Front, Longitudinal
Engine Model/Code B47D20B
Engine displacement 1995 cm3
121.74 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 84 mm
3.31 in.
Piston Stroke 90 mm
3.54 in.
Compression ratio 16.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Twin-power turbo, Intercooler
Engine oil capacity 5.5 l
5.81 US qt | 4.84 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8.8 l
9.3 US qt | 7.74 UK qt
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1840 kg
4056.51 lbs.
Max. weight 2530 kg
5577.7 lbs.
Max load 690 kg
1521.19 lbs.
Trunk (boot) space – minimum 560 l
19.78 cu. ft.
Trunk (boot) space – maximum 1700 l
60.03 cu. ft.
Fuel tank capacity 66 l
17.44 US gal | 14.52 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 2000 kg
4409.25 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 90 kg
198.42 lbs.
Dimensions
Length 4963 mm
195.39 in.
Width 1868 mm
73.54 in.
Height 1498 mm
58.98 in.
Wheelbase 2975 mm
117.13 in.
Front track 1605 mm
63.19 in.
Rear (Back) track 1630 mm
64.17 in.
Ride height (ground clearance) 140 mm
5.51 in.
Drag coefficient (Cd) 0.26
Minimum turning circle (turning diameter) 12.4 m
40.68 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) and the electric motor permanently drive the four wheels of the car with the ability to work only in mixed mode.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 8 gears, automatic transmission Steptronic
Front suspension Double wishbone
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/55 R17 101Y XL
Wheel rims size 7.5J x 17
