Specifications: BMW 5 Series Touring (G31 LCI, facelift 2020) 530e (292 Hp) Plug-in Hybrid xDrive Steptronic 2020, 2021, 2022, 2023, 2024

2021 BMW 5 Series Touring (G31 LCI, facelift 2020) - Photo 1

BMW 5 Series Touring (G31 LCI, facelift 2020) 530e (292 Hp) Plug-in Hybrid xDrive Steptronic – Full specifications
General information
Brand BMW
Model 5 Series
Generation 5 Series Touring (G31 LCI, facelift 2020)
Modification (Engine) 530e (292 Hp) Plug-in Hybrid xDrive Steptronic
Start of production July, 2020 year
End of production February, 2024 year
Powertrain Architecture PHEV (Plug-in Hybrid Electric Vehicle)
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Combined fuel consumption (WLTP) 1.8-2.2 l/100 km
130.7 – 106.9 US mpg
156.9 – 128.4 UK mpg
55.6 – 45.5 km/l
CO2 emissions (WLTP) 41-51 g/km
Fuel consumption (economy) – combined (NEDC, WLTP equivalent) 2.2-2.4 l/100 km
106.9 – 98 US mpg
128.4 – 117.7 UK mpg
45.5 – 41.7 km/l
CO2 emissions (NEDC, WLTP equivalent) 50-54 g/km
Fuel Type Petrol / electricity
Acceleration 0 – 100 km/h 6.1 sec
Acceleration 0 – 62 mph 6.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 5.8 sec
Maximum speed 225 km/h
139.81 mph
Emission standard Euro 6d
Weight-to-power ratio 6.7 kg/Hp, 149 Hp/tonne
Weight-to-torque ratio 4.7 kg/Nm, 214.3 Nm/tonne
Electric cars and hybrids specs
Gross battery capacity 12 kWh
Battery voltage 354 V
Battery technology Lithium-ion (Li-Ion)
Battery location Under the rear seats
All-electric range (WLTP) 47-53 km
29.2 – 32.93 mi
Average Energy consumption (WLTP) 18.5-19.9 kWh/100 km

29.77 – 32.03 kWh/100 mi
113 – 105 MPGe
5.4 – 5 km/kWh
3.4 – 3.1 mi/kWh
Average Energy consumption (NEDC, WLTP equivalent) 16.1-16.7 kWh/100 km

25.91 – 26.88 kWh/100 mi
130 – 125 MPGe
6.2 – 6 km/kWh
3.9 – 3.7 mi/kWh
Max speed (electric) 140 km/h

86.99 mph
Charging ports Log in to see.Log in to see.
Electric motor 1
Electric motor power 109 Hp @ 3140 rpm.
Electric motor Torque 265 Nm @ 100-2500 rpm.

195.45 lb.-ft. @ 100-2500 rpm.
Electric motor location Between the combustion engine and the transmission
System power 292 Hp
System torque 420 Nm
309.78 lb.-ft.
Internal combustion engine specs
Power 184 Hp @ 5000-6500 rpm.
Power per litre 92.1 Hp/l
Torque 300 Nm @ 1350-4000 rpm.
221.27 lb.-ft. @ 1350-4000 rpm.
Engine layout Front, Longitudinal
Engine Model/Code B48B20A
Engine displacement 1998 cm3
121.93 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82 mm
3.23 in.
Piston Stroke 94.6 mm
3.72 in.
Compression ratio 11:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Twin-power turbo, Intercooler
Valvetrain VALVETRONIC
Engine oil capacity 5.25 l
5.55 US qt | 4.62 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 9.9 l
10.46 US qt | 8.71 UK qt
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1960 kg
4321.06 lbs.
Max. weight 2610 kg
5754.07 lbs.
Max load 650 kg
1433 lbs.
Trunk (boot) space – minimum 430 l
15.19 cu. ft.
Trunk (boot) space – maximum 1560 l
55.09 cu. ft.
Fuel tank capacity 46 l
12.15 US gal | 10.12 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 2000 kg
4409.25 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 90 kg
198.42 lbs.
Dimensions
Length 4963 mm
195.39 in.
Width 1868 mm
73.54 in.
Height 1498 mm
58.98 in.
Wheelbase 2975 mm
117.13 in.
Front track 1605 mm
63.19 in.
Rear (Back) track 1630 mm
64.17 in.
Ride height (ground clearance) 143 mm
5.63 in.
Drag coefficient (Cd) 0.29
Minimum turning circle (turning diameter) 12.4 m
40.68 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) and the electric motor permanently drive the four wheels of the car with the ability to work in full electric or mixed mode.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 8 gears, automatic transmission Steptronic
Front suspension Double wishbone
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 245/45 R18
Wheel rims size 8J x 18
