Specifications: BMW 7 Series (G11) 740d (320 Hp) xDrive Steptronic 2015, 2016, 2017, 2018, 2019

2015 BMW 7 Series (G11) - Photo 1

BMW 7 Series (G11) 740d (320 Hp) xDrive Steptronic – Full specifications
General information
Brand BMW
Model 7 Series
Generation 7 Series (G11)
Modification (Engine) 740d (320 Hp) xDrive Steptronic
Start of production 2015 year
End of production 2019 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 6.2-6.6 l/100 km
37.9 – 35.6 US mpg
45.6 – 42.8 UK mpg
16.1 – 15.2 km/l
Fuel consumption (economy) – extra urban 4.2-4.5 l/100 km
56 – 52.3 US mpg
67.3 – 62.8 UK mpg
23.8 – 22.2 km/l
Fuel consumption (economy) – combined 4.9-5.3 l/100 km
48 – 44.4 US mpg
57.6 – 53.3 UK mpg
20.4 – 18.9 km/l
CO2 emissions 129-139 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 5.2 sec
Acceleration 0 – 62 mph 5.2 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 4.9 sec
Maximum speed 250 km/h
155.34 mph
Emission standard Euro 6
Weight-to-power ratio 5.8 kg/Hp, 172 Hp/tonne
Weight-to-torque ratio 2.7 kg/Nm, 365.6 Nm/tonne
Engine specs
Power 320 Hp @ 4000 rpm.
Power per litre 106.9 Hp/l
Torque 680 Nm @ 1750-2250 rpm.
501.54 lb.-ft. @ 1750-2250 rpm.
Engine layout Front, Longitudinal
Engine Model/Code B57D30B
Engine displacement 2993 cm3
182.64 cu. in.
Number of cylinders 6
Engine configuration Inline
Cylinder Bore 84 mm
3.31 in.
Piston Stroke 90 mm
3.54 in.
Compression ratio 16.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Twin-power turbo, Intercooler
Engine oil capacity 6.5 l
6.87 US qt | 5.72 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 11.9 l
12.57 US qt | 10.47 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1860 kg
4100.6 lbs.
Max. weight 2530 kg
5577.7 lbs.
Max load 670 kg
1477.1 lbs.
Trunk (boot) space – minimum 515 l
18.19 cu. ft.
Fuel tank capacity 78 l
20.61 US gal | 17.16 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 2300 kg
5070.63 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 100 kg
220.46 lbs.
Dimensions
Length 5098 mm
200.71 in.
Width 1902 mm
74.88 in.
Height 1478 mm
58.19 in.
Wheelbase 3070 mm
120.87 in.
Front track 1617 mm
63.66 in.
Rear (Back) track 1646 mm
64.8 in.
Ride height (ground clearance) 135 mm
5.31 in.
Drag coefficient (Cd) 0.25
Minimum turning circle (turning diameter) 12.5 m
41.01 ft.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 8 gears, automatic transmission Steptronic
Front suspension Double wishbone
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 225/60 R17 99Y; 245/50 R18; 245/45 R19; 275/40 R19; 245/40 R20; 275/35 R20; 245/35 R21; 275/30 R21
Wheel rims size 7.5J x 17; 8J x 18; 8.5J x 19; 9.5J x 19; 8.5J x 20; 10J x 20; 8.5J x 21; 10J x 21
