Specifications: Daihatsu YRV 1.3 i 16V Allrad (87 Hp) 2001, 2002, 2003, 2004, 2005

2001 Daihatsu YRV - Photo 1

Daihatsu YRV 1.3 i 16V Allrad (87 Hp) – Full specifications
General information
Brand Daihatsu
Model YRV
Generation YRV
Modification (Engine) 1.3 i 16V Allrad (87 Hp)
Start of production 2001 year
End of production 2005 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 8.3 l/100 km
28.34 US mpg
34.03 UK mpg
12.05 km/l
Fuel consumption (economy) – extra urban 5.5 l/100 km
42.77 US mpg
51.36 UK mpg
18.18 km/l
Fuel consumption (economy) – combined 6.3 l/100 km
37.34 US mpg
44.84 UK mpg
15.87 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 11.1 sec
Acceleration 0 – 62 mph 11.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.5 sec
Maximum speed 170 km/h
105.63 mph
Weight-to-power ratio 11.6 kg/Hp, 86.1 Hp/tonne
Weight-to-torque ratio 8.4 kg/Nm, 118.8 Nm/tonne
Engine specs
Power 87 Hp @ 6000 rpm.
Power per litre 67 Hp/l
Torque 120 Nm @ 3200 rpm.
88.51 lb.-ft. @ 3200 rpm.
Engine layout Front, Longitudinal
Engine Model/Code K3-VE
Engine displacement 1298 cm3
79.21 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 72 mm
2.83 in.
Piston Stroke 79.7 mm
3.14 in.
Compression ratio 10:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 3.6 l
3.8 US qt | 3.17 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 4 l
4.23 US qt | 3.52 UK qt

Space, Volume and weights
Kerb Weight 1010 kg
2226.67 lbs.
Max. weight 1420 kg
3130.56 lbs.
Max load 410 kg
903.9 lbs.
Trunk (boot) space – minimum 240 l
8.48 cu. ft.
Trunk (boot) space – maximum 1076 l
38 cu. ft.
Fuel tank capacity 37 l
9.77 US gal | 8.14 UK gal
Dimensions
Length 3765 mm
148.23 in.
Width 1620 mm
63.78 in.
Height 1550 mm
61.02 in.
Wheelbase 2355 mm
92.72 in.
Front track 1395 mm
54.92 in.
Rear (Back) track 1360 mm
53.54 in.
Minimum turning circle (turning diameter) 8.8 m
28.87 ft.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Spring Strut
Rear suspension Coil spring
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 175/60 R14 T
