Specifications: Dodge Caravan III SWB 2.4 (152 Hp) 1996, 1997, 1998, 1999, 2000

1996 Dodge Caravan III SWB - Photo 1

Dodge Caravan III SWB 2.4 (152 Hp) – Full specifications
General information
Brand Dodge
Model Caravan
Generation Caravan III SWB
Modification (Engine) 2.4 (152 Hp)
Start of production 1996 year
End of production 2000 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 7
Doors 5
Performance specs
Fuel consumption (economy) – urban 11.8 l/100 km
19.93 US mpg
23.94 UK mpg
8.47 km/l
Fuel consumption (economy) – extra urban 7.3 l/100 km
32.22 US mpg
38.7 UK mpg
13.7 km/l
Fuel Type Petrol (Gasoline)
Maximum speed 170 km/h
105.63 mph
Weight-to-power ratio 10.6 kg/Hp, 94.4 Hp/tonne
Weight-to-torque ratio 7.1 kg/Nm, 140.4 Nm/tonne
Engine specs
Power 152 Hp @ 5200 rpm.
Power per litre 62.6 Hp/l
Torque 226 Nm @ 4000 rpm.
166.69 lb.-ft. @ 4000 rpm.
Engine layout Front, Transverse
Engine Model/Code EDZ
Engine displacement 2429 cm3
148.23 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 87.5 mm
3.44 in.
Piston Stroke 101 mm
3.98 in.
Compression ratio 9.4:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 4.3 l
4.54 US qt | 3.78 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 9 l
9.51 US qt | 7.92 UK qt

Space, Volume and weights
Kerb Weight 1610 kg
3549.44 lbs.
Max. weight 2454 kg
5410.14 lbs.
Max load 844 kg
1860.7 lbs.
Trunk (boot) space – minimum 450 l
15.89 cu. ft.
Trunk (boot) space – maximum 4140 l
146.2 cu. ft.
Fuel tank capacity 75 l
19.81 US gal | 16.5 UK gal
Dimensions
Length 4733 mm
186.34 in.
Width 1920 mm
75.59 in.
Height 1740 mm
68.5 in.
Wheelbase 2878 mm
113.31 in.
Front track 1600 mm
62.99 in.
Rear (Back) track 1626 mm
64.02 in.
Ride height (ground clearance) 140 mm
5.51 in.
Drag coefficient (Cd) 0.35
Minimum turning circle (turning diameter) 11.5 m
37.73 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Wishbone
Rear suspension Rigid axle suspension
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 205/75 R14
Wheel rims size 14
