| General information | |
|---|---|
| Brand | Dodge |
| Model | Caravan |
| Generation | Caravan III SWB |
| Modification (Engine) | 3.0 V6 (152 Hp) 4×4 Automatic |
| Start of production | 1996 year |
| End of production | 2000 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan |
| Seats | 7 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Maximum speed | 170 km/h 105.63 mph |
| Weight-to-power ratio | 11 kg/Hp, 91.1 Hp/tonne |
| Weight-to-torque ratio | 7 kg/Nm, 143.2 Nm/tonne |
| Engine specs | |
| Power | 152 Hp @ 5200 rpm. |
| Power per litre | 51.1 Hp/l |
| Torque | 239 Nm @ 4000 rpm. 176.28 lb.-ft. @ 4000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 6G72 |
| Engine displacement | 2972 cm3 181.36 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 91.1 mm 3.59 in. |
| Piston Stroke | 76 mm 2.99 in. |
| Compression ratio | 8.9:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | SOHC |
| Engine oil capacity | 4.3 l 4.54 US qt | 3.78 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 9.5 l 10.04 US qt | 8.36 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1669 kg 3679.52 lbs. |
| Max. weight | 2454 kg 5410.14 lbs. |
| Max load | 785 kg 1730.63 lbs. |
| Trunk (boot) space – minimum | 450 l 15.89 cu. ft. |
| Trunk (boot) space – maximum | 4140 l 146.2 cu. ft. |
| Fuel tank capacity | 75 l 19.81 US gal | 16.5 UK gal |
| Dimensions | |
| Length | 4733 mm 186.34 in. |
| Width | 1920 mm 75.59 in. |
| Height | 1740 mm 68.5 in. |
| Wheelbase | 2878 mm 113.31 in. |
| Front track | 1600 mm 62.99 in. |
| Rear (Back) track | 1626 mm 64.02 in. |
| Ride height (ground clearance) | 140 mm 5.51 in. |
| Drag coefficient (Cd) | 0.35 |
| Minimum turning circle (turning diameter) | 11.5 m 37.73 ft. |
| Drivetrain, brakes and suspension specs | |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 3 gears, automatic transmission |
| Front suspension | Wishbone |
| Rear suspension | Rigid axle suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 205/75 R14; 215/70 R15; 215/65 R16 |
| Wheel rims size | 14; 15; 16 |
