| General information | |
|---|---|
| Brand | Dodge |
| Model | RAM |
| Generation | Ram 1500 Regular Cab Short Bed (BR/BE) |
| Modification (Engine) | 3.9 V6 (175 Hp) |
| Start of production | 1994 year |
| End of production | 1998 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Pick-up |
| Seats | 3 |
| Doors | 2 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Engine specs | |
| Power | 175 Hp @ 4800 rpm. |
| Power per litre | 44.7 Hp/l |
| Torque | 312 Nm @ 3200 rpm. 230.12 lb.-ft. @ 3200 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | 239 Magnum |
| Engine displacement | 3917 cm3 239.03 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 99.31 mm 3.91 in. |
| Piston Stroke | 84.07 mm 3.31 in. |
| Compression ratio | 9.1:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | OHV |
| Engine oil capacity | 3.8 l 4.02 US qt | 3.34 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 19 l 20.08 US qt | 16.72 UK qt |
|
|
|
| Space, Volume and weights | |
| Max. weight | 2726 kg 6009.8 lbs. |
| Fuel tank capacity | 98 l 25.89 US gal | 21.56 UK gal |
| Permitted trailer load with brakes (12%) | 1633 kg 3600.15 lbs. |
| Dimensions | |
| Length | 5077 mm 199.88 in. |
| Width | 2017 mm 79.41 in. |
| Height | 1826 mm 71.89 in. |
| Wheelbase | 3023 mm 119.02 in. |
| Minimum turning circle (turning diameter) | 12.4 m 40.68 ft. |
| Approach angle | 25.2° |
| Departure angle | 23.8° |
| Ramp-over (brakeover) angle | 18.4° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Independent coil spring, Transverse stabilizer |
| Rear suspension | Leaf spring |
| Front brakes | Disc |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 225/75 R16 |
| Wheel rims size | 7J x 16 |
