Specifications: Dodge Ram 3500 Club Cab Long Bed (BRBE) DRW 5.9 Cummins TD (160 Hp) 4×4 Automatic 1994, 1995, 1996, 1997, 1998

Dodge Ram 3500 Club Cab Long Bed (BR/BE) DRW 5.9 Cummins TD (160 Hp) 4×4 Automatic – Full specifications
General information
Brand Dodge
Model RAM
Generation Ram 3500 Club Cab Long Bed (BR/BE)
Modification (Engine) DRW 5.9 Cummins TD (160 Hp) 4×4 Automatic
Start of production 1994 year
End of production 1998 year
Powertrain Architecture Internal Combustion engine
Body type Pick-up
Seats 6
Doors 2
Performance specs
Fuel Type Diesel
Engine specs
Power 160 Hp @ 2500 rpm.
Power per litre 27.2 Hp/l
Torque 542 Nm @ 1500 rpm.
399.76 lb.-ft. @ 1500 rpm.
Engine layout Front, Longitudinal
Engine displacement 5883 cm3
359 cu. in.
Number of cylinders 6
Engine configuration Inline
Cylinder Bore 102 mm
4.02 in.
Piston Stroke 120 mm
4.72 in.
Compression ratio 17.5:1
Number of valves per cylinder 2
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 10.4 l
10.99 US qt | 9.15 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 24.5 l
25.89 US qt | 21.56 UK qt

Space, Volume and weights
Max. weight 4763 kg
10500.62 lbs.
Permitted trailer load with brakes (12%) 4400 kg
9700.34 lbs.
Dimensions
Length 6198 mm
244.02 in.
Width including mirrors 2383 mm
93.82 in.
Height 1961 mm
77.2 in.
Wheelbase 3937 mm
155 in.
Approach angle 33.4°
Departure angle 28.9°
Ramp-over (brakeover) angle 21.4°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 4 gears, automatic transmission
Front suspension Dependent spring suspension with anti-roll bar
Rear suspension Rigid axle suspension, Leaf spring
Front brakes Disc
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 215/85 R16
Wheel rims size 6J x 16
