| General information | |
|---|---|
| Brand | Dodge |
| Model | RAM |
| Generation | Ram 3500 Club Cab Long Bed (BR/BE) |
| Modification (Engine) | DRW 5.9 Cummins TD (175 Hp) 4×4 |
| Start of production | 1994 year |
| End of production | 1998 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Pick-up |
| Seats | 6 |
| Doors | 2 |
| Performance specs | |
| Fuel Type | Diesel |
| Engine specs | |
| Power | 175 Hp @ 2500 rpm. |
| Power per litre | 29.7 Hp/l |
| Torque | 583 Nm @ 1600 rpm. 430 lb.-ft. @ 1600 rpm. |
| Engine layout | Front, Longitudinal |
| Engine displacement | 5883 cm3 359 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | Inline |
| Cylinder Bore | 102 mm 4.02 in. |
| Piston Stroke | 120 mm 4.72 in. |
| Compression ratio | 17.5:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 10.4 l 10.99 US qt | 9.15 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 24.5 l 25.89 US qt | 21.56 UK qt |
|
|
|
| Space, Volume and weights | |
| Max. weight | 4581 kg 10099.38 lbs. |
| Permitted trailer load with brakes (12%) | 4400 kg 9700.34 lbs. |
| Dimensions | |
| Length | 6198 mm 244.02 in. |
| Width including mirrors | 2383 mm 93.82 in. |
| Height | 1961 mm 77.2 in. |
| Wheelbase | 3937 mm 155 in. |
| Approach angle | 33.4° |
| Departure angle | 28.9° |
| Ramp-over (brakeover) angle | 21.4° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Dependent spring suspension with anti-roll bar |
| Rear suspension | Rigid axle suspension, Leaf spring |
| Front brakes | Disc |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 215/85 R16 |
| Wheel rims size | 6J x 16 |
