Specifications: Dodge Viper ZB II Convertible 8.4i V10 20V SRT-10 (600 Hp) 2007, 2008, 2009, 2010

2008 Dodge Viper ZB II Convertible - Photo 1

Dodge Viper ZB II Convertible 8.4i V10 20V SRT-10 (600 Hp) – Full specifications
General information
Brand Dodge
Model Viper
Generation Viper ZB II Convertible
Modification (Engine) 8.4i V10 20V SRT-10 (600 Hp)
Start of production 2007 year
End of production 2010 year
Powertrain Architecture Internal Combustion engine
Body type Roadster
Seats 2
Doors 2
Performance specs
Fuel consumption (economy) – urban 30.5 l/100 km
7.71 US mpg
9.26 UK mpg
3.28 km/l
Fuel consumption (economy) – extra urban 12.4 l/100 km
18.97 US mpg
22.78 UK mpg
8.06 km/l
Fuel consumption (economy) – combined 19.4 l/100 km
12.12 US mpg
14.56 UK mpg
5.15 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 3.9 sec
Acceleration 0 – 62 mph 3.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 3.7 sec
Maximum speed 325 km/h
201.95 mph
Weight-to-power ratio 2.6 kg/Hp, 384.6 Hp/tonne
Weight-to-torque ratio 2.1 kg/Nm, 487.2 Nm/tonne
Engine specs
Power 600 Hp @ 6100 rpm.
Power per litre 71.6 Hp/l
Torque 760 Nm @ 5000 rpm.
560.55 lb.-ft. @ 5000 rpm.
Engine layout Front, Longitudinal
Engine displacement 8382 cm3
511.5 cu. in.
Number of cylinders 10
Engine configuration V-engine
Cylinder Bore 103 mm
4.06 in.
Piston Stroke 100.6 mm
3.96 in.
Compression ratio 10.2:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Engine oil capacity 9.5 l
10.04 US qt | 8.36 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 15 l
15.85 US qt | 13.2 UK qt

Space, Volume and weights
Kerb Weight 1560 kg
3439.21 lbs.
Max. weight 1800 kg
3968.32 lbs.
Max load 240 kg
529.11 lbs.
Trunk (boot) space – maximum 240 l
8.48 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Dimensions
Length 4459 mm
175.55 in.
Width 1911 mm
75.24 in.
Height 1210 mm
47.64 in.
Wheelbase 2510 mm
98.82 in.
Front track 1565 mm
61.61 in.
Rear (Back) track 1547 mm
60.91 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 275/35 R19; 345/30 R19
