Specifications: Ferrari 750 Monza 3.0 (260 Hp) 1954

1954 Ferrari 750 Monza - Photo 1

Ferrari 750 Monza 3.0 (260 Hp) – Full specifications
General information
Brand Ferrari
Model 750 Monza
Generation 750 Monza
Modification (Engine) 3.0 (260 Hp)
Start of production 1954 year
End of production 1954 year
Powertrain Architecture Internal Combustion engine
Body type Roadster
Seats 2
Doors 2
Performance specs
Fuel consumption (economy) – combined 26 l/100 km
9 US mpg
10.9 UK mpg
3.8 km/l
Fuel Type Petrol (Gasoline)
Maximum speed 264 km/h
164.04 mph
Weight-to-power ratio 2.9 kg/Hp, 342.1 Hp/tonne
Engine specs
Power 260 Hp
Power per litre 86.7 Hp/l
Maximum engine speed 6000 rpm.
Engine layout Front, Longitudinal
Engine displacement 2999 cm3
183.01 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 103 mm
4.06 in.
Piston Stroke 90 mm
3.54 in.
Compression ratio 8.6:1
Number of valves per cylinder 2
Fuel injection system Carburettor
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 16 l
16.91 US qt | 14.08 UK qt

Space, Volume and weights
Kerb Weight 760 kg
1675.51 lbs.
Fuel tank capacity 150 l
39.63 US gal | 33 UK gal
Dimensions
Wheelbase 2250 mm
88.58 in.
Front track 1278 mm
50.31 in.
Rear (Back) track 1284 mm
50.55 in.
Ride height (ground clearance) 140 mm
5.51 in.
Minimum turning circle (turning diameter) 10 m
32.81 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Coil spring
Rear suspension Suspension De-Dion, Leaf spring
Front brakes Drum
Rear brakes Drum
Steering type Worm-reduction unit
Tires size 185/80 R16
Wheel rims size 5J x 16
