Specifications: Fiat 124 Spider 1400 Sport (90 Hp) 1966, 1967, 1968, 1969

1966 Fiat 124 Spider - Photo 1

Fiat 124 Spider 1400 Sport (90 Hp) – Full specifications
General information
Brand Fiat
Model 124
Generation 124 Spider
Modification (Engine) 1400 Sport (90 Hp)
Start of production July, 1966 year
End of production March, 1969 year
Powertrain Architecture Internal Combustion engine
Body type Cabriolet
Seats 2
Doors 2
Performance specs
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 12.5 sec
Acceleration 0 – 62 mph 12.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.9 sec
Maximum speed 170 km/h
105.63 mph
Engine specs
Power 90 Hp @ 6500 rpm.
Power per litre 62.6 Hp/l
Torque 108 Nm @ 4000 rpm.
79.66 lb.-ft. @ 4000 rpm.
Engine layout Front, Longitudinal
Engine Model/Code 124 AC.000
Engine displacement 1438 cm3
87.75 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 80 mm
3.15 in.
Piston Stroke 71.5 mm
2.81 in.
Compression ratio 8.9:1
Number of valves per cylinder 2
Fuel injection system Carburettor
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 3.75 l
3.96 US qt | 3.3 UK qt
Coolant 7.5 l
7.93 US qt | 6.6 UK qt

Space, Volume and weights
Fuel tank capacity 45 l
11.89 US gal | 9.9 UK gal
Dimensions
Length 3971 mm
156.34 in.
Width 1613 mm
63.5 in.
Height 1250 mm
49.21 in.
Wheelbase 2280 mm
89.76 in.
Front track 1350 mm
53.15 in.
Rear (Back) track 1320 mm
51.97 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 4 gears, manual transmission
Front suspension Double wishbone
Rear suspension Transverse stabilizer, Trailing arm
Front brakes Disc
Rear brakes Disc
Steering type Worm-reduction unit
