| General information | |
|---|---|
| Brand | Fiat |
| Model | 500X |
| Generation | 500X Cross/Off-Road |
| Modification (Engine) | 1.4 MultiAir II (140 Hp) Automatic |
| Start of production | 2017 year |
| End of production | 2018 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV, Crossover |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 7.2 l/100 km 32.7 US mpg 39.2 UK mpg 13.9 km/l |
| Fuel consumption (economy) – extra urban | 4.9 l/100 km 48 US mpg 57.6 UK mpg 20.4 km/l |
| Fuel consumption (economy) – combined | 5.7 l/100 km 41.3 US mpg 49.6 UK mpg 17.5 km/l |
| CO2 emissions | 133 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 9.8 sec |
| Acceleration 0 – 62 mph | 9.8 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 9.3 sec |
| Maximum speed | 190 km/h 118.06 mph |
| Emission standard | Euro 6 |
| Engine specs | |
| Power | 140 Hp @ 5000 rpm. |
| Power per litre | 102.3 Hp/l |
| Torque | 230 Nm @ 1750 rpm. 169.64 lb.-ft. @ 1750 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 55263624, 55283775 |
| Engine displacement | 1368 cm3 83.48 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 72 mm 2.83 in. |
| Piston Stroke | 84 mm 3.31 in. |
| Compression ratio | 10:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | SOHC |
| Engine oil capacity | 3.6 l 3.8 US qt | 3.17 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 5.2 l 5.49 US qt | 4.58 UK qt |
|
|
|
| Space, Volume and weights | |
| Fuel tank capacity | 48 l 12.68 US gal | 10.56 UK gal |
| Dimensions | |
| Length | 4273 mm 168.23 in. |
| Width | 1796 mm 70.71 in. |
| Height | 1608 mm 63.31 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, automatic transmission DCT |
| Front suspension | Independent type McPherson |
| Rear suspension | McPherson |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/60 R16; 215/55 R17; 225/45 R18 |
| Wheel rims size | 16; 17; 18 |
