Specifications: Fiat 600 (187) 1.1i (40 Hp) 2005, 2006, 2007, 2008, 2009, 2010

2005 Fiat 600 (187) - Photo 1

Fiat 600 (187) 1.1i (40 Hp) – Full specifications
General information
Brand Fiat
Model 600
Generation 600 (187)
Modification (Engine) 1.1i (40 Hp)
Start of production 2005 year
End of production 2010 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 3
Performance specs
Fuel consumption (economy) – urban 8.3 l/100 km
28.3 US mpg
34 UK mpg
12 km/l
Fuel consumption (economy) – extra urban 4.7 l/100 km
50 US mpg
60.1 UK mpg
21.3 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 14.5 sec
Acceleration 0 – 62 mph 14.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 13.8 sec
Maximum speed 150 km/h
93.21 mph
Weight-to-power ratio 18.4 kg/Hp, 54.4 Hp/tonne
Weight-to-torque ratio 8.4 kg/Nm, 119.7 Nm/tonne
Engine specs
Power 40 Hp @ 3750 rpm.
Power per litre 36.1 Hp/l
Torque 88 Nm @ 2750 rpm.
64.91 lb.-ft. @ 2750 rpm.
Engine layout Front, Transverse
Engine Model/Code 1170 A1.046
Engine displacement 1108 cm3
67.61 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 70 mm
2.76 in.
Piston Stroke 72 mm
2.83 in.
Compression ratio 9.6:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Engine oil capacity 3.8 l
4.02 US qt | 3.34 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 4.8 l
5.07 US qt | 4.22 UK qt

Space, Volume and weights
Kerb Weight 735 kg
1620.4 lbs.
Max. weight 1210 kg
2667.59 lbs.
Max load 475 kg
1047.2 lbs.
Trunk (boot) space – minimum 170 l
6 cu. ft.
Trunk (boot) space – maximum 810 l
28.6 cu. ft.
Fuel tank capacity 40 l
10.57 US gal | 8.8 UK gal
Dimensions
Length 3337 mm
131.38 in.
Width 1508 mm
59.37 in.
Height 1420 mm
55.91 in.
Wheelbase 2200 mm
86.61 in.
Front track 1277 mm
50.28 in.
Rear (Back) track 1272 mm
50.08 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Disc
Rear brakes Drum
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 155/65 R13
Wheel rims size 13
