Specifications: Fiat Egea Station Wagon (358) 1.6 Multijet II (120 Hp) 2016, 2017, 2018, 2019

Fiat Egea Station Wagon (358) 1.6 Multijet II (120 Hp) – Full specifications
General information
Brand Fiat
Model Egea
Generation Egea Station Wagon (358)
Modification (Engine) 1.6 Multijet II (120 Hp)
Start of production 2016 year
End of production 2019 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 4.4 l/100 km
53.5 US mpg
64.2 UK mpg
22.7 km/l
Fuel consumption (economy) – extra urban 3.3 l/100 km
71.3 US mpg
85.6 UK mpg
30.3 km/l
Fuel consumption (economy) – combined 3.7 l/100 km
63.6 US mpg
76.3 UK mpg
27 km/l
CO2 emissions 98 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 10.1 sec
Acceleration 0 – 62 mph 10.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.6 sec
Maximum speed 200 km/h
124.27 mph
Emission standard Euro 6
Weight-to-power ratio 11 kg/Hp, 90.9 Hp/tonne
Weight-to-torque ratio 4.1 kg/Nm, 242.4 Nm/tonne
Engine specs
Power 120 Hp @ 3750 rpm.
Power per litre 75.1 Hp/l
Torque 320 Nm @ 1750 rpm.
236.02 lb.-ft. @ 1750 rpm.
Engine layout Front, Transverse
Engine Model/Code 55260384
Engine displacement 1598 cm3
97.52 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 79.5 mm
3.13 in.
Piston Stroke 80.5 mm
3.17 in.
Compression ratio 16.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 4.8 l
5.07 US qt | 4.22 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.1 l
6.45 US qt | 5.37 UK qt
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1320 kg
2910.1 lbs.
Max. weight 1870 kg
4122.64 lbs.
Max load 550 kg
1212.54 lbs.
Trunk (boot) space – minimum 550 l
19.42 cu. ft.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (12%) 1200 kg
2645.55 lbs.
Permitted trailer load without brakes 500 kg
1102.31 lbs.
Permitted towbar download 60 kg
132.28 lbs.
Dimensions
Length 4571 mm
179.96 in.
Width 1792 mm
70.55 in.
Width including mirrors 2002 mm
78.82 in.
Height 1512 mm
59.53 in.
Wheelbase 2638 mm
103.86 in.
Front track 1542 mm
60.71 in.
Rear (Back) track 1543 mm
60.75 in.
Front overhang 893 mm
35.16 in.
Rear overhang 1040 mm
40.94 in.
Minimum turning circle (turning diameter) 10.9 m
35.76 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent type McPherson
Rear suspension Torsion
Front brakes Disc, 281×26 mm
Rear brakes Disc, 264×10 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/55 R16; 225/45 R17
Wheel rims size 6.5J x 16; 7J x 17
