Specifications: Fiat Fullback Double Cab 2.4 (154 Hp) 4WD S&S SCR 2016, 2017

2017 Fiat Fullback Double Cab - Photo 1

Fiat Fullback Double Cab 2.4 (154 Hp) 4WD S&S SCR – Full specifications
General information
Brand Fiat
Model Fullback
Generation Fullback Double Cab
Modification (Engine) 2.4 (154 Hp) 4WD S&S SCR
Start of production 2016 year
End of production 2017 year
Powertrain Architecture Internal Combustion engine
Body type Pick-up
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – combined 6.9 l/100 km
34.1 US mpg
40.9 UK mpg
14.5 km/l
CO2 emissions 180 g/km
Fuel Type Diesel
Maximum speed 174 km/h
108.12 mph
Emission standard Euro 6
Weight-to-power ratio 12.2 kg/Hp, 82.1 Hp/tonne
Weight-to-torque ratio 4.9 kg/Nm, 202.7 Nm/tonne
Engine specs
Power 154 Hp @ 3500 rpm.
Power per litre 63.1 Hp/l
Torque 380 Nm @ 2500 rpm.
280.27 lb.-ft. @ 2500 rpm.
Engine layout Front, Longitudinal
Engine Model/Code 4N15
Engine displacement 2442 cm3
149.02 cu. in.
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 8.3 l
8.77 US qt | 7.3 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.7 l
8.14 US qt | 6.78 UK qt
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1875 kg
4133.67 lbs.
Max. weight 2905 kg
6404.43 lbs.
Max load 1030 kg
2270.76 lbs.
Fuel tank capacity 75 l
19.81 US gal | 16.5 UK gal
Permitted trailer load with brakes (12%) 3100 kg
6834.33 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Dimensions
Length 5285 mm
208.07 in.
Width 1815 mm
71.46 in.
Height 1780 mm
70.08 in.
Wheelbase 3000 mm
118.11 in.
Front track 1520 mm
59.84 in.
Rear (Back) track 1515 mm
59.65 in.
Front overhang 865 mm
34.06 in.
Rear overhang 1420 mm
55.91 in.
Ride height (ground clearance) 205 mm
8.07 in.
Minimum turning circle (turning diameter) 11.8 m
38.71 ft.
Approach angle 30°
Departure angle 22°
Ramp-over (brakeover) angle 24°
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent coil spring
Rear suspension Leaf spring
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 245/70 R16; 245/65 R17
Wheel rims size 16; 17
