Specifications: Fiat Stilo Multi Wagon (facelift 2006) 1.9 Multijet 8V (120 Hp) 2006, 2007, 2008

2006 Fiat Stilo Multi Wagon (facelift 2006) - Photo 1

Fiat Stilo Multi Wagon (facelift 2006) 1.9 Multijet 8V (120 Hp) – Full specifications
General information
Brand Fiat
Model Stilo
Generation Stilo Multi Wagon (facelift 2006)
Modification (Engine) 1.9 Multijet 8V (120 Hp)
Start of production 2006 year
End of production 2008 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 7.1 l/100 km
33.1 US mpg
39.8 UK mpg
14.1 km/l
Fuel consumption (economy) – extra urban 4.7 l/100 km
50 US mpg
60.1 UK mpg
21.3 km/l
Fuel consumption (economy) – combined 5.6 l/100 km
42 US mpg
50.4 UK mpg
17.9 km/l
CO2 emissions 148 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 11.3 sec
Acceleration 0 – 62 mph 11.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.7 sec
Maximum speed 193 km/h
119.92 mph
Emission standard Euro 4
Weight-to-power ratio 11.8 kg/Hp, 85.1 Hp/tonne
Weight-to-torque ratio 5.5 kg/Nm, 180.9 Nm/tonne
Engine specs
Power 120 Hp @ 4000 rpm.
Power per litre 62.8 Hp/l
Torque 255 Nm @ 2000 rpm.
188.08 lb.-ft. @ 2000 rpm.
Engine layout Front, Transverse
Engine Model/Code 192A8000
Engine displacement 1910 cm3
116.56 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82 mm
3.23 in.
Piston Stroke 90.4 mm
3.56 in.
Compression ratio 18:1
Number of valves per cylinder 2
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain OHC
Engine oil capacity 4.7 l
4.97 US qt | 4.14 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7 l
7.4 US qt | 6.16 UK qt

Space, Volume and weights
Kerb Weight 1410 kg
3108.52 lbs.
Max. weight 1920 kg
4232.88 lbs.
Max load 510 kg
1124.36 lbs.
Trunk (boot) space – minimum 510 l
18.01 cu. ft.
Trunk (boot) space – maximum 1480 l
52.27 cu. ft.
Fuel tank capacity 58 l
15.32 US gal | 12.76 UK gal
Max. roof load 80 kg
176.37 lbs.
Permitted trailer load with brakes (12%) 1000 kg
2204.62 lbs.
Permitted trailer load without brakes 500 kg
1102.31 lbs.
Permitted towbar download 60 kg
132.28 lbs.
Dimensions
Length 4516 mm
177.8 in.
Width 1756 mm
69.13 in.
Height 1570 mm
61.81 in.
Wheelbase 2600 mm
102.36 in.
Front track 1514 mm
59.61 in.
Rear (Back) track 1508 mm
59.37 in.
Front overhang 893 mm
35.16 in.
Rear overhang 1023 mm
40.28 in.
Minimum turning circle (turning diameter) 10.6 m
34.78 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent type McPherson
Rear suspension Coil spring, Torsion
Front brakes Ventilated discs, 284 mm
Rear brakes Disc, 251 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 195/65 R15
Wheel rims size 6.5 J x 15
