Specifications: Fiat Talento Combi 1.6 Ecojet (95 Hp) L1H1 M1 2016, 2017, 2018, 2019, 2020, 2021

2017 Fiat Talento Combi - Photo 1

Fiat Talento Combi 1.6 Ecojet (95 Hp) L1H1 M1 – Full specifications
General information
Brand Fiat
Model Talento
Generation Talento Combi
Modification (Engine) 1.6 Ecojet (95 Hp) L1H1 M1
Start of production 2016 year
End of production 2021 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 6-9
Doors 5
Performance specs
Fuel consumption (economy) – urban 6.8 l/100 km
34.6 US mpg
41.5 UK mpg
14.7 km/l
Fuel consumption (economy) – extra urban 5.4 l/100 km
43.6 US mpg
52.3 UK mpg
18.5 km/l
Fuel consumption (economy) – combined 6 l/100 km
39.2 US mpg
47.1 UK mpg
16.7 km/l
CO2 emissions 155 g/km
Fuel Type Diesel
Maximum speed 153 km/h
95.07 mph
Emission standard Euro 6
Weight-to-power ratio 19.4 kg/Hp, 51.5 Hp/tonne
Weight-to-torque ratio 7.1 kg/Nm, 141 Nm/tonne
Engine specs
Power 95 Hp @ 3500 rpm.
Power per litre 59.4 Hp/l
Torque 260 Nm @ 1500 rpm.
191.77 lb.-ft. @ 1500 rpm.
Engine layout Front, Transverse
Engine Model/Code R9M 413
Engine displacement 1598 cm3
97.52 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 80 mm
3.15 in.
Piston Stroke 79.5 mm
3.13 in.
Compression ratio 15.45:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 7.4 l
7.82 US qt | 6.51 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 9.5 l
10.04 US qt | 8.36 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1844-1906 kg
4065.32 – 4202.01 lbs.
Max. weight 2830-2925 kg
6239.08 – 6448.52 lbs.
Max load 986-1019 kg
2173.76 – 2246.51 lbs.
Trunk (boot) space – minimum 1000 l
35.31 cu. ft.
Trunk (boot) space – maximum 3200 l
113.01 cu. ft.
Fuel tank capacity 80 l
21.13 US gal | 17.6 UK gal
AdBlue tank 20 l
5.28 US gal | 4.4 UK gal
Permitted trailer load with brakes (12%) 2000 kg
4409.25 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Dimensions
Length 4999 mm
196.81 in.
Width 1956 mm
77.01 in.
Width including mirrors 2283 mm
89.88 in.
Height 1971 mm
77.6 in.
Wheelbase 3098 mm
121.97 in.
Front track 1615 mm
63.58 in.
Rear (Back) track 1628 mm
64.09 in.
Front overhang 933 mm
36.73 in.
Rear overhang 968 mm
38.11 in.
Minimum turning circle (turning diameter) 12.40 m
40.68 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Semi-independent, coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 205/65 R16; 215/60 R17
Wheel rims size 16; 17
