Specifications: Fiat Toro 1.8 E-Torq (139 Hp) Automatic 2016, 2017, 2018, 2019, 2020, 2021

2016 Fiat Toro - Photo 1

Fiat Toro 1.8 E-Torq (139 Hp) Automatic – Full specifications
General information
Brand Fiat
Model Toro
Generation Toro
Modification (Engine) 1.8 E-Torq (139 Hp) Automatic
Start of production 2016 year
End of production 2021 year
Powertrain Architecture Internal Combustion engine
Body type Pick-up
Seats 5
Doors 4
Performance specs
Fuel Type Petrol / Ethanol – E85
Maximum speed 176 km/h
109.36 mph
Emission standard Euro 5
Weight-to-power ratio 11.9 kg/Hp, 84.2 Hp/tonne
Weight-to-torque ratio 8.7 kg/Nm, 114.5 Nm/tonne
Engine specs
Power 139 Hp @ 5750 rpm.
Power per litre 79.6 Hp/l
Torque 189 Nm @ 3750 rpm.
139.4 lb.-ft. @ 3750 rpm.
Engine layout Front, Transverse
Engine Model/Code 370 A0.011
Engine displacement 1747 cm3
106.61 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 80.5 mm
3.17 in.
Piston Stroke 85.8 mm
3.38 in.
Compression ratio 12.5:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Turbocharger
Engine oil capacity 4.3 l
4.54 US qt | 3.78 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5.6 l
5.92 US qt | 4.93 UK qt

Space, Volume and weights
Kerb Weight 1651 kg
3639.83 lbs.
Trunk (boot) space – minimum 820 l
28.96 cu. ft.
Fuel tank capacity 60 l
15.85 US gal | 13.2 UK gal
Permitted trailer load with brakes (12%) 650 kg
1433 lbs.
Permitted trailer load without brakes 400 kg
881.85 lbs.
Dimensions
Length 4915 mm
193.5 in.
Width 1844 mm
72.6 in.
Width including mirrors 2033 mm
80.04 in.
Height 1735 mm
68.31 in.
Wheelbase 2990 mm
117.72 in.
Front track 1547 mm
60.91 in.
Rear (Back) track 1575 mm
62.01 in.
Front overhang 920 mm
36.22 in.
Rear overhang 1005 mm
39.57 in.
Ride height (ground clearance) 224 mm
8.82 in.
Minimum turning circle (turning diameter) 12.2 m
40.03 ft.
Approach angle 24.7°
Departure angle 28.1°
Ramp-over (brakeover) angle 20.9°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 215/65 R16
Wheel rims size 6.5J x 16
