Specifications: Ford Bronco III 5.0 V8 (152 Hp) AWD 1980, 1981, 1982, 1983, 1984, 1985, 1986

1980 Ford Bronco III - Photo 1

Ford Bronco III 5.0 V8 (152 Hp) AWD – Full specifications
General information
Brand Ford
Model Bronco
Generation Bronco III
Modification (Engine) 5.0 V8 (152 Hp) AWD
Start of production 1980 year
End of production 1986 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 5
Doors 3
Performance specs
Fuel consumption (economy) – urban 18.1 l/100 km
13 US mpg
15.6 UK mpg
5.5 km/l
Fuel consumption (economy) – extra urban 16.8 l/100 km
14 US mpg
16.8 UK mpg
6 km/l
Fuel consumption (economy) – combined 18.1 l/100 km
13 US mpg
15.6 UK mpg
5.5 km/l
Fuel Type Petrol (Gasoline)
Engine specs
Power 152 Hp @ 3400 rpm.
Power per litre 30.8 Hp/l
Torque 366 Nm @ 2000 rpm.
269.95 lb.-ft. @ 2000 rpm.
Engine layout Front, Longitudinal
Engine Model/Code 302
Engine displacement 4942 cm3
301.58 cu. in.
Number of cylinders 8
Engine configuration V-engine
Cylinder Bore 101.6 mm
4 in.
Piston Stroke 76.2 mm
3 in.
Compression ratio 8.9:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine

Space, Volume and weights
Max. weight 2000 kg
4409.25 lbs.
Dimensions
Length 4511 mm
177.6 in.
Width 1961 mm
77.2 in.
Height 1852 mm
72.91 in.
Wheelbase 2659 mm
104.69 in.
Front track 1654 mm
65.12 in.
Rear (Back) track 1636 mm
64.41 in.
Ride height (ground clearance) 234 mm
9.21 in.
Drag coefficient (Cd) 0.65
Minimum turning circle (turning diameter) 11.13 m
36.52 ft.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 4 gears, manual transmission
Front brakes Disc
Rear brakes Drum
Tires size 235/75 R15
Wheel rims size 15
