Specifications: Ford C-MAX II 1.6 EcoBoost (182 Hp) S&S 2010, 2011, 2012, 2013, 2014, 2015

2011 Ford C-MAX II - Photo 1

Ford C-MAX II 1.6 EcoBoost (182 Hp) S&S – Full specifications
General information
Brand Ford
Model C-MAX
Generation C-MAX II
Modification (Engine) 1.6 EcoBoost (182 Hp) S&S
Start of production 2010 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type MPV
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 7.8 l/100 km
30.2 US mpg
36.2 UK mpg
12.8 km/l
Fuel consumption (economy) – extra urban 5.3 l/100 km
44.4 US mpg
53.3 UK mpg
18.9 km/l
Fuel consumption (economy) – combined 6.2 l/100 km
37.9 US mpg
45.6 UK mpg
16.1 km/l
CO2 emissions 144 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 8.5 sec
Acceleration 0 – 62 mph 8.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.1 sec
Maximum speed 217 km/h
134.84 mph
Emission standard Euro 5
Weight-to-power ratio 7.2 kg/Hp, 138.9 Hp/tonne
Weight-to-torque ratio 5.5 kg/Nm, 183.2 Nm/tonne
Engine specs
Power 182 Hp @ 5700 rpm.
Power per litre 114 Hp/l
Torque 240 Nm @ 1600-5000 rpm.
177.01 lb.-ft. @ 1600-5000 rpm.
Engine layout Front, Transverse
Engine Model/Code JTDB
Engine displacement 1596 cm3
97.39 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 79 mm
3.11 in.
Piston Stroke 81.4 mm
3.2 in.
Compression ratio 10:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 4.1 l
4.33 US qt | 3.61 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5.5 l
5.81 US qt | 4.84 UK qt
Engine systems Start & Stop System

Space, Volume and weights
Kerb Weight 1310 kg
2888.06 lbs.
Max. weight 1900 kg
4188.78 lbs.
Max load 590 kg
1300.73 lbs.
Trunk (boot) space – minimum 432 l
15.26 cu. ft.
Trunk (boot) space – maximum 1723 l
60.85 cu. ft.
Fuel tank capacity 55 l
14.53 US gal | 12.1 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 690 kg
1521.19 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4380 mm
172.44 in.
Width 1828 mm
71.97 in.
Width with mirrors folded 1858 mm
73.15 in.
Width including mirrors 2067 mm
81.38 in.
Height 1626 mm
64.02 in.
Wheelbase 2648 mm
104.25 in.
Front track 1544 mm
60.79 in.
Rear (Back) track 1554 mm
61.18 in.
Minimum turning circle (turning diameter) 10.7 m
35.1 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 215/55 R16
Wheel rims size 7.0 J x 16
