Specifications: Ford Econoline (E) 4.2 i V6 (197 Hp) 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999

1993 Ford Econoline (E) - Photo 1

Ford Econoline (E) 4.2 i V6 (197 Hp) – Full specifications
General information
Brand Ford
Model Econoline
Generation Econoline (E)
Modification (Engine) 4.2 i V6 (197 Hp)
Start of production 1992 year
End of production 1999 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 8
Doors 4
Performance specs
Fuel consumption (economy) – urban 16.8 l/100 km
14 US mpg
16.8 UK mpg
6 km/l
Fuel consumption (economy) – extra urban 13.1 l/100 km
18 US mpg
21.6 UK mpg
7.6 km/l
Fuel Type Petrol (Gasoline)
Maximum speed 160 km/h
99.42 mph
Weight-to-power ratio 12 kg/Hp, 83.1 Hp/tonne
Weight-to-torque ratio 7 kg/Nm, 143 Nm/tonne
Engine specs
Power 197 Hp @ 4750 rpm.
Power per litre 47 Hp/l
Torque 339 Nm @ 3000 rpm.
250.03 lb.-ft. @ 3000 rpm.
Engine layout Front, Longitudinal
Engine displacement 4192 cm3
255.81 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 95 mm
3.74 in.
Piston Stroke 98.7 mm
3.89 in.
Compression ratio 9.3:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine

Space, Volume and weights
Kerb Weight 2370 kg
5224.96 lbs.
Max. weight 3280 kg
7231.16 lbs.
Max load 910 kg
2006.21 lbs.
Trunk (boot) space – maximum 7263 l
256.49 cu. ft.
Fuel tank capacity 132 l
34.87 US gal | 29.04 UK gal
Dimensions
Length 5382 mm
211.89 in.
Width 2014 mm
79.29 in.
Height 2050 mm
80.71 in.
Wheelbase 3505 mm
137.99 in.
Front track 1763 mm
69.41 in.
Rear (Back) track 1702 mm
67.01 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 4 gears, automatic transmission
Front suspension Coil spring
Rear suspension Leaf spring
Front brakes Disc
Rear brakes Disc
Power steering Hydraulic Steering
Tires size 235/75 R15
