Specifications: Ford Escape III 1.6 EcoBoost (178 Hp) 4WD Automatic 2013, 2014, 2015, 2016

2013 Ford Escape III - Photo 1

Ford Escape III 1.6 EcoBoost (178 Hp) 4WD Automatic – Full specifications
General information
Brand Ford
Model Escape
Generation Escape III
Modification (Engine) 1.6 EcoBoost (178 Hp) 4WD Automatic
Start of production 2013 year
End of production 2016 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 10.7 l/100 km
22 US mpg
26.4 UK mpg
9.3 km/l
Fuel consumption (economy) – extra urban 7.8 l/100 km
30.2 US mpg
36.2 UK mpg
12.8 km/l
Fuel consumption (economy) – combined 9.4 l/100 km
25 US mpg
30.1 UK mpg
10.6 km/l
Fuel Type Petrol (Gasoline)
Weight-to-power ratio 9.3 kg/Hp, 107.7 Hp/tonne
Weight-to-torque ratio 6.6 kg/Nm, 150.6 Nm/tonne
Engine specs
Power 178 Hp @ 5700 rpm.
Power per litre 111.5 Hp/l
Torque 249 Nm @ 2500 rpm.
183.65 lb.-ft. @ 2500 rpm.
Engine layout Front, Transverse
Engine displacement 1596 cm3
97.39 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 79 mm
3.11 in.
Piston Stroke 81.2 mm
3.2 in.
Compression ratio 10:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC, Ti-VCT
Engine oil capacity 4.1 l
4.33 US qt | 3.61 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8 l
8.45 US qt | 7.04 UK qt

Space, Volume and weights
Kerb Weight 1653 kg
3644.24 lbs.
Trunk (boot) space – minimum 971 l
34.29 cu. ft.
Trunk (boot) space – maximum 1920 l
67.8 cu. ft.
Fuel tank capacity 58 l
15.32 US gal | 12.76 UK gal
Permitted trailer load with brakes (12%) 907 kg
1999.59 lbs.
Dimensions
Length 4524 mm
178.11 in.
Width 1839 mm
72.4 in.
Width with mirrors folded 1905 mm
75 in.
Width including mirrors 2078 mm
81.81 in.
Height 1684 mm
66.3 in.
Wheelbase 2690 mm
105.91 in.
Front track 1562 mm
61.5 in.
Rear (Back) track 1565 mm
61.61 in.
Ride height (ground clearance) 201 mm
7.91 in.
Minimum turning circle (turning diameter) 11.6 m
38.06 ft.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 6 gears, automatic transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 235/55 R17; 235/45 R19
Wheel rims size 17; 19
