Specifications: Ford Escape IV (facelift 2023) 2.5 (210 Hp) Plug-in Hybrid eCVT 2023, 2024, 2025

2023 Ford Escape IV (facelift 2023) - Photo 1

Ford Escape IV (facelift 2023) 2.5 (210 Hp) Plug-in Hybrid eCVT – Full specifications
General information
Brand Ford
Model Escape
Generation Escape IV (facelift 2023)
Modification (Engine) 2.5 (210 Hp) Plug-in Hybrid eCVT
Start of production 2023 year
Powertrain Architecture PHEV (Plug-in Hybrid Electric Vehicle)
Body type SUV
Seats 5
Doors 5
Performance specs
Fuel Type Petrol / electricity
Weight-to-power ratio 8.4 kg/Hp, 118.6 Hp/tonne
Weight-to-torque ratio 8.4 kg/Nm, 118.6 Nm/tonne
Electric cars and hybrids specs
Battery technology Lithium-ion (Li-Ion)
Battery location Below the floor, under the rear seats
All-electric range 59.5 km
36.97 mi
Charging ports Log in to see.Log in to see.
Electric motor 1
Electric motor location Integrated into the transmission
System power 210 Hp
Internal combustion engine specs
Power 163 Hp @ 6250 rpm.
Power per litre 65.5 Hp/l
Torque 210 Nm @ 4500 rpm.
154.89 lb.-ft. @ 4500 rpm.
Engine layout Front, Transverse
Engine displacement 2490 cm3
151.95 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 88.9 mm
3.5 in.
Piston Stroke 100.08 mm
3.94 in.
Compression ratio 13:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC, IVCT
Engine oil capacity 5.4 l
5.71 US qt | 4.75 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 9.6 l
10.14 US qt | 8.45 UK qt

Space, Volume and weights
Kerb Weight 1771 kg
3904.39 lbs.
Trunk (boot) space – minimum 974 l
34.4 cu. ft.
Trunk (boot) space – maximum 1722 l
60.81 cu. ft.
Fuel tank capacity 42 l
11.1 US gal | 9.24 UK gal
Permitted trailer load with brakes (12%) 680 kg
1499.14 lbs.
Dimensions
Length 4575 mm
180.12 in.
Width 1882 mm
74.09 in.
Width with mirrors folded 1999 mm
78.7 in.
Width including mirrors 2174 mm
85.59 in.
Height 1679 mm
66.1 in.
Wheelbase 2710 mm
106.69 in.
Front track 1585 mm
62.4 in.
Rear (Back) track 1570 mm
61.81 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode.
Drive wheel Front wheel drive
Number of gears and type of gearbox automatic transmission eCVT
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Disc
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/60 R18
