| General information | |
|---|---|
| Brand | Ford |
| Model | Escort |
| Generation | Escort VII Hatch (GAL,AFL) |
| Modification (Engine) | 1.8 TD (70 Hp) |
| Start of production | 1996 year |
| End of production | 1999 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 3/5 |
| Performance specs | |
| Fuel consumption (economy) – combined | 6.5 l/100 km 36.2 US mpg 43.5 UK mpg 15.4 km/l |
| Fuel Type | Diesel |
| Maximum speed | 163 km/h 101.28 mph |
| Weight-to-power ratio | 15.6 kg/Hp, 63.9 Hp/tonne |
| Weight-to-torque ratio | 8.1 kg/Nm, 123.3 Nm/tonne |
| Engine specs | |
| Power | 70 Hp @ 4500 rpm. |
| Power per litre | 39.9 Hp/l |
| Torque | 135 Nm @ 2500 rpm. 99.57 lb.-ft. @ 2500 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | RVA |
| Engine displacement | 1753 cm3 106.97 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 82.5 mm 3.25 in. |
| Piston Stroke | 82 mm 3.23 in. |
| Compression ratio | 21.5:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Precombustion chamber injection |
| Engine aspiration | Turbocharger |
| Valvetrain | OHC |
| Engine oil capacity | 5.1 l 5.39 US qt | 4.49 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 9.3 l 9.83 US qt | 8.18 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1095 kg 2414.06 lbs. |
| Max. weight | 1600 kg 3527.4 lbs. |
| Max load | 505 kg 1113.33 lbs. |
| Trunk (boot) space – minimum | 380 l 13.42 cu. ft. |
| Trunk (boot) space – maximum | 735 l 25.96 cu. ft. |
| Fuel tank capacity | 55 l 14.53 US gal | 12.1 UK gal |
| Dimensions | |
| Length | 4104 mm 161.57 in. |
| Width | 1691 mm 66.57 in. |
| Height | 1398 mm 55.04 in. |
| Wheelbase | 2525 mm 99.41 in. |
| Front track | 1440 mm 56.69 in. |
| Rear (Back) track | 1462 mm 57.56 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Wishbone |
| Rear suspension | Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 175/70 R13 T |
