Specifications: Ford Excursion 7.3 TD (253 Hp) 4WD Automatic 2001, 2002, 2003, 2004, 2005

2000 Ford Excursion - Photo 1

Ford Excursion 7.3 TD (253 Hp) 4WD Automatic – Full specifications
General information
Brand Ford
Model Excursion
Generation Excursion
Modification (Engine) 7.3 TD (253 Hp) 4WD Automatic
Start of production 2001 year
End of production 2005 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 8-9
Doors 5
Performance specs
Fuel Type Diesel
Maximum speed 153 km/h
95.07 mph
Weight-to-power ratio 14.2 kg/Hp, 70.3 Hp/tonne
Weight-to-torque ratio 5.3 kg/Nm, 190.4 Nm/tonne
Engine specs
Power 253 Hp @ 2600 rpm.
Power per litre 34.8 Hp/l
Torque 685 Nm @ 1600 rpm.
505.23 lb.-ft. @ 1600 rpm.
Engine layout Front, Longitudinal
Engine displacement 7270 cm3
443.64 cu. in.
Number of cylinders 8
Engine configuration V-engine
Cylinder Bore 104.4 mm
4.11 in.
Piston Stroke 106.2 mm
4.18 in.
Compression ratio 17:1
Number of valves per cylinder 2
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain OHC
Engine oil capacity 14.2 l
15 US qt | 12.49 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 31 l
32.76 US qt | 27.28 UK qt

Space, Volume and weights
Kerb Weight 3597 kg
7930.03 lbs.
Max. weight 4173 kg
9199.89 lbs.
Max load 576 kg
1269.86 lbs.
Trunk (boot) space – minimum 1359 l
47.99 cu. ft.
Trunk (boot) space – maximum 4146 l
146.41 cu. ft.
Fuel tank capacity 167 l
44.12 US gal | 36.73 UK gal
Dimensions
Length 5758 mm
226.69 in.
Width 2032 mm
80 in.
Height 2034 mm
80.08 in.
Wheelbase 3482 mm
137.09 in.
Front track 1737 mm
68.39 in.
Rear (Back) track 1730 mm
68.11 in.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 4 gears, automatic transmission
Front suspension Leaf spring
Rear suspension Leaf spring
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Worm-reduction unit
Power steering Hydraulic Steering
Tires size 265/75 R16
