Specifications: Ford Explorer II 5.0 V8 4WD XLT (210 Hp) 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003

1995 Ford Explorer II - Photo 1

Ford Explorer II 5.0 V8 4WD XLT (210 Hp) – Full specifications
General information
Brand Ford
Model Explorer
Generation Explorer II
Modification (Engine) 5.0 V8 4WD XLT (210 Hp)
Start of production 1996 year
End of production 2003 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 5
Doors 5
Performance specs
Fuel Type Petrol (Gasoline)
Weight-to-power ratio 9 kg/Hp, 111.1 Hp/tonne
Weight-to-torque ratio 5.1 kg/Nm, 197.3 Nm/tonne
Engine specs
Power 210 Hp @ 4600 rpm.
Power per litre 42.5 Hp/l
Torque 373 Nm @ 3200 rpm.
275.11 lb.-ft. @ 3200 rpm.
Engine layout Front, Longitudinal
Engine displacement 4942 cm3
301.58 cu. in.
Number of cylinders 8
Engine configuration V-engine
Cylinder Bore 101.6 mm
4 in.
Piston Stroke 76.2 mm
3 in.
Compression ratio 8.8:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Engine oil capacity 4.7 l
4.97 US qt | 4.14 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 12.1 l
12.79 US qt | 10.65 UK qt

Space, Volume and weights
Kerb Weight 1891 kg
4168.94 lbs.
Trunk (boot) space – minimum 1206 l
42.59 cu. ft.
Trunk (boot) space – maximum 2311 l
81.61 cu. ft.
Fuel tank capacity 66 l
17.44 US gal | 14.52 UK gal
Dimensions
Length 4788 mm
188.5 in.
Width 1783 mm
70.2 in.
Height 1699 mm
66.89 in.
Wheelbase 2832 mm
111.5 in.
Front track 1494 mm
58.82 in.
Rear (Back) track 1488 mm
58.58 in.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 4 gears, automatic transmission
Front suspension Double wishbone
Rear suspension Leaf spring
Front brakes Disc
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 225/70 R15
