| General information | |
|---|---|
| Brand | Ford |
| Model | Explorer |
| Generation | Explorer IV |
| Modification (Engine) | 4.0 i V6 4WD (212 Hp) |
| Start of production | 2006 year |
| End of production | 2010 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 15.7 l/100 km 15 US mpg 18 UK mpg 6.4 km/l |
| Fuel consumption (economy) – extra urban | 11.8 l/100 km 19.9 US mpg 23.9 UK mpg 8.5 km/l |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 10.2 sec |
| Acceleration 0 – 62 mph | 10.2 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 9.7 sec |
| Maximum speed | 158 km/h 98.18 mph |
| Weight-to-power ratio | 9.8 kg/Hp, 102.4 Hp/tonne |
| Weight-to-torque ratio | 6 kg/Nm, 166.2 Nm/tonne |
| Engine specs | |
| Power | 212 Hp @ 5100 rpm. |
| Power per litre | 53 Hp/l |
| Torque | 344 Nm @ 3700 rpm. 253.72 lb.-ft. @ 3700 rpm. |
| Engine layout | Front, Longitudinal |
| Engine displacement | 3998 cm3 243.97 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 100.33 mm 3.95 in. |
| Piston Stroke | 84.3 mm 3.32 in. |
| Compression ratio | 9.7:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Engine oil capacity | 4.7 l 4.97 US qt | 4.14 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 11.5 l 12.15 US qt | 10.12 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2070 kg 4563.57 lbs. |
| Max. weight | 2667 kg 5879.73 lbs. |
| Max load | 597 kg 1316.16 lbs. |
| Trunk (boot) space – minimum | 391 l 13.81 cu. ft. |
| Trunk (boot) space – maximum | 2492 l 88 cu. ft. |
| Fuel tank capacity | 85 l 22.45 US gal | 18.7 UK gal |
| Dimensions | |
| Length | 4813 mm 189.49 in. |
| Width | 1832 mm 72.13 in. |
| Height | 1814 mm 71.42 in. |
| Wheelbase | 2890 mm 113.78 in. |
| Front track | 1547 mm 60.91 in. |
| Rear (Back) track | 1555 mm 61.22 in. |
| Drivetrain, brakes and suspension specs | |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 5 gears, automatic transmission |
| Front suspension | Torsion |
| Rear suspension | Coil spring |
| Front brakes | Disc |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 235/70 R16 |
