| General information | |
|---|---|
| Brand | Ford |
| Model | Explorer |
| Generation | Explorer VI (facelift 2024) |
| Modification (Engine) | 2.3 EcoBoost (300 Hp) Automatic |
| Start of production | February, 2024 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 6-7 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Engine specs | |
| Power | 300 Hp |
| Power per litre | 132.7 Hp/l |
| Torque | 420 Nm 309.78 lb.-ft. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | EcoBoost |
| Engine displacement | 2261 cm3 137.97 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 84 mm 3.31 in. |
| Piston Stroke | 102 mm 4.02 in. |
| Compression ratio | 10.6:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection and Multi-port manifold injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC, TI-VCT |
| Engine oil capacity | 4.7 l 4.97 US qt | 4.14 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 12.8 l 13.53 US qt | 11.26 UK qt |
| Engine systems | Start & Stop System |
|
|
|
| Space, Volume and weights | |
| Trunk (boot) space – minimum | 462 l 16.32 cu. ft. |
| Trunk (boot) space – maximum | 2430 l 85.81 cu. ft. |
| Fuel tank capacity | 68 l 17.96 US gal | 14.96 UK gal |
| Permitted trailer load with brakes (12%) | 2268 kg 5000.08 lbs. |
| Dimensions | |
| Length | 5047 mm 198.7 in. |
| Width | 2004 mm 78.9 in. |
| Width with mirrors folded | 2101 mm 82.72 in. |
| Width including mirrors | 2268 mm 89.29 in. |
| Height | 1768-1783 mm 69.61 – 70.2 in. |
| Wheelbase | 3025 mm 119.09 in. |
| Front track | 1699 mm 66.89 in. |
| Rear (Back) track | 1699 mm 66.89 in. |
| Front overhang | 853 mm 33.58 in. |
| Rear overhang | 1169 mm 46.02 in. |
| Ride height (ground clearance) | 193-208 mm 7.6 – 8.19 in. |
| Approach angle | 19.7-20.5° |
| Departure angle | 21.1-21.5° |
| Ramp-over (brakeover) angle | 16.5-17.6° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 10 gears, automatic transmission |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 255/65 R18; 255/55 R20; 275/45 R21 |
| Wheel rims size | 18; 20; 21 |
