Specifications: Ford F-350 Super Duty IV Crew Cab Long box 6.2 V8 (385 Hp) 4×4 Automatic DRW 2017, 2018, 2019

2018 Ford F-350 Super Duty IV Crew Cab Long box - Photo 1

Ford F-350 Super Duty IV Crew Cab Long box 6.2 V8 (385 Hp) 4×4 Automatic DRW – Full specifications
General information
Brand Ford
Model F-350 Super Duty
Generation F-350 Super Duty IV Crew Cab Long box
Modification (Engine) 6.2 V8 (385 Hp) 4×4 Automatic DRW
Start of production 2017 year
End of production 2019 year
Powertrain Architecture Internal Combustion engine
Body type Pick-up
Seats 6
Doors 4
Performance specs
Fuel Type Petrol (Gasoline)
Weight-to-power ratio 8.7 kg/Hp, 115 Hp/tonne
Weight-to-torque ratio 5.7 kg/Nm, 174.2 Nm/tonne
Engine specs
Power 385 Hp @ 5750 rpm.
Power per litre 62 Hp/l
Torque 583 Nm @ 3800 rpm.
430 lb.-ft. @ 3800 rpm.
Engine layout Front, Longitudinal
Engine displacement 6211 cm3
379.02 cu. in.
Number of cylinders 8
Engine configuration V-engine
Cylinder Bore 102.1 mm
4.02 in.
Piston Stroke 95 mm
3.74 in.
Compression ratio 9.8:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain SOHC
Engine oil capacity 6.6 l
6.97 US qt | 5.81 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 20.2 l
21.35 US qt | 17.77 UK qt

Space, Volume and weights
Kerb Weight 3347 kg
7378.87 lbs.
Trunk (boot) space – minimum 2222 l
78.47 cu. ft.
Fuel tank capacity 182 l
48.08 US gal | 40.03 UK gal
Permitted trailer load with brakes (12%) 7031 kg
15500.7 lbs.
Dimensions
Length 6761 mm
266.18 in.
Width 2438 mm
95.98 in.
Width including mirrors 2690 mm
105.91 in.
Height 2057 mm
80.98 in.
Wheelbase 4470 mm
175.98 in.
Front track 1755 mm
69.09 in.
Rear (Back) track 1897 mm
74.69 in.
Front overhang 970 mm
38.19 in.
Rear overhang 1321 mm
52.01 in.
Ride height (ground clearance) 198 mm
7.8 in.
Approach angle 19.1°
Departure angle 20.1°
Ramp-over (brakeover) angle 20.8°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 6 gears, automatic transmission TorqShift
Front suspension Dependent spring suspension with anti-roll bar, Trailing arm
Rear suspension Rigid axle suspension, Leaf spring
Front brakes Ventilated discs, 363 mm
Rear brakes Ventilated discs, 363 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Cone worm with recirculation balls
Power steering Hydraulic Steering
Tires size 245/75 R17
Wheel rims size 17
