Specifications: Ford F-350 Super Duty IV Crew Cab Short box 6.2 V8 (385 Hp) Automatic SRW 2017, 2018, 2019

2018 Ford F-350 Super Duty IV Crew Cab Short box - Photo 1

Ford F-350 Super Duty IV Crew Cab Short box 6.2 V8 (385 Hp) Automatic SRW – Full specifications
General information
Brand Ford
Model F-350 Super Duty
Generation F-350 Super Duty IV Crew Cab Short box
Modification (Engine) 6.2 V8 (385 Hp) Automatic SRW
Start of production 2017 year
End of production 2019 year
Powertrain Architecture Internal Combustion engine
Body type Pick-up
Seats 6
Doors 4
Performance specs
Fuel Type Petrol (Gasoline)
Weight-to-power ratio 7.4 kg/Hp, 135.2 Hp/tonne
Weight-to-torque ratio 4.9 kg/Nm, 204.7 Nm/tonne
Engine specs
Power 385 Hp @ 5750 rpm.
Power per litre 62 Hp/l
Torque 583 Nm @ 3800 rpm.
430 lb.-ft. @ 3800 rpm.
Engine layout Front, Longitudinal
Engine displacement 6211 cm3
379.02 cu. in.
Number of cylinders 8
Engine configuration V-engine
Cylinder Bore 102.1 mm
4.02 in.
Piston Stroke 95 mm
3.74 in.
Compression ratio 9.8:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain SOHC
Engine oil capacity 6.6 l
6.97 US qt | 5.81 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 20.2 l
21.35 US qt | 17.77 UK qt

Space, Volume and weights
Kerb Weight 2848-2874 kg
6278.77 – 6336.09 lbs.
Trunk (boot) space – minimum 1852 l
65.4 cu. ft.
Fuel tank capacity 182 l
48.08 US gal | 40.03 UK gal
Permitted trailer load with brakes (12%) 5761 kg
12700.83 lbs.
Dimensions
Length 6350 mm
250 in.
Width 2032 mm
80 in.
Width including mirrors 2690 mm
105.91 in.
Height 1986 mm
78.19 in.
Wheelbase 4059 mm
159.8 in.
Front track 1735 mm
68.31 in.
Rear (Back) track 1707 mm
67.2 in.
Front overhang 970 mm
38.19 in.
Rear overhang 1321 mm
52.01 in.
Ride height (ground clearance) 216 mm
8.5 in.
Approach angle 17.6°
Departure angle 17.9°
Ramp-over (brakeover) angle 17.8°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission TorqShift
Front suspension Independent coil spring, Trailing arm
Rear suspension Rigid axle suspension, Leaf spring
Front brakes Ventilated discs, 363 mm
Rear brakes Ventilated discs, 363 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Cone worm with recirculation balls
Power steering Hydraulic Steering
Tires size 245/75 R17
