Specifications: Ford F-Series F-100 II 3.5 215 Six (101 Hp) Automatic 1952, 1953, 1954

Ford F-Series F-100 II 3.5 215 Six (101 Hp) Automatic – Full specifications
General information
Brand	Ford
Model	F-Series F-100/F-150
Generation	F-Series F-100 II
Modification (Engine)	3.5 215 Six (101 Hp) Automatic
Start of production	1952 year
End of production	1954 year
Powertrain Architecture	Internal Combustion engine
Body type	Pick-up
Seats	2-3
Doors	2
Performance specs
Fuel Type	Petrol (Gasoline)
Engine specs
Power	101 Hp @ 3500 rpm.
Power per litre	28.6 Hp/l
Torque	251 Nm @ 1300-1700 rpm. 185.13 lb.-ft. @ 1300-1700 rpm.
Engine layout	Front, Longitudinal
Engine displacement	3528 cm³ 215.29 cu. in.
Number of cylinders	6
Engine configuration	Inline
Cylinder Bore	90.42 mm 3.56 in.
Piston Stroke	91.44 mm 3.6 in.
Compression ratio	7:1
Fuel injection system	Carburettor
Engine aspiration	Naturally aspirated engine
Valvetrain	OHV

Space, Volume and weights
Max. weight	2268 kg 5000.08 lbs.
Trunk (boot) space – minimum	1274 l 44.99 cu. ft.
Fuel tank capacity	64 l 16.91 US gal \| 14.08 UK gal
Dimensions
Length	4804 mm 189.13 in.
Width	1811 mm 71.3 in.
Height	1913 mm 75.31 in.
Wheelbase	2794 mm 110 in.
Front track	1539 mm 60.59 in.
Rear (Back) track	1524 mm 60 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture	The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel	Rear wheel drive
Number of gears and type of gearbox	automatic transmission Fordomatic
Front suspension	Leaf spring
Rear suspension	Leaf spring
Wheel rims size	16
