Specifications: Ford F-Series F-100 V 5.9 360 V8 (215 Hp) 1968, 1969, 1970, 1971, 1972

Ford F-Series F-100 V 5.9 360 V8 (215 Hp) – Full specifications
General information
Brand	Ford
Model	F-Series F-100/F-150
Generation	F-Series F-100 V
Modification (Engine)	5.9 360 V8 (215 Hp)
Start of production	1968 year
End of production	1972 year
Powertrain Architecture	Internal Combustion engine
Body type	Pick-up
Seats	3
Doors	2
Performance specs
Fuel Type	Petrol (Gasoline)
Engine specs
Power	215 Hp @ 4400 rpm.
Power per litre	36.4 Hp/l
Torque	443 Nm @ 2600 rpm. 326.74 lb.-ft. @ 2600 rpm.
Engine layout	Front, Longitudinal
Engine displacement	5899 cm³ 359.98 cu. in.
Number of cylinders	8
Engine configuration	V-engine
Cylinder Bore	102.87 mm 4.05 in.
Piston Stroke	88.9 mm 3.5 in.
Compression ratio	8.4:1
Fuel injection system	Carburettor
Engine aspiration	Naturally aspirated engine

Space, Volume and weights
Max. weight	2268 kg 5000.08 lbs.
Trunk (boot) space – minimum	1274-2163 l 44.99 – 76.39 cu. ft.
Fuel tank capacity	74 l 19.55 US gal \| 16.28 UK gal
Dimensions
Length	4636-5138 mm 182.52 – 202.28 in.
Wheelbase	2921-3327 mm 115 – 130.98 in.
Wading depth	658-660 mm 25.91 – 25.98 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture	The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel	Rear wheel drive
Number of gears and type of gearbox	3 gears, manual transmission
Front suspension	Independent coil spring
Front brakes	Drum
Rear brakes	Drum
Steering type	Cone worm with recirculation balls
Power steering	Electric Steering
Tires size	215/75 R15; 225/75 R15
Wheel rims size	7J x 15
