Specifications: Ford F-Series F-150 VI SuperCab 7.5 460 V8 (220 Hp) Automatic 1977, 1978, 1979

Ford F-Series F-150 VI SuperCab 7.5 460 V8 (220 Hp) Automatic – Full specifications
General information
Brand Ford
Model F-Series F-100/F-150
Generation F-Series F-150 VI SuperCab
Modification (Engine) 7.5 460 V8 (220 Hp) Automatic
Start of production 1977 year
End of production 1979 year
Powertrain Architecture Internal Combustion engine
Body type Pick-up
Seats 6
Doors 2
Performance specs
Fuel Type Petrol (Gasoline)
Engine specs
Power 220 Hp
Power per litre 29.2 Hp/l
Engine layout Front, Longitudinal
Engine displacement 7538 cm3
460 cu. in.
Number of cylinders 8
Engine configuration V-engine
Piston Stroke 97.79 mm
3.85 in.
Number of valves per cylinder 4
Fuel injection system Carburettor
Engine aspiration Naturally aspirated engine

Space, Volume and weights
Max. weight 2812 kg
6199.4 lbs.
Trunk (boot) space – minimum 1727-2084 l
60.99 – 73.6 cu. ft.
Fuel tank capacity 73 l
19.28 US gal | 16.06 UK gal
Dimensions
Length 5362-5773 mm
211.1 – 227.28 in.
Wheelbase 3531-3937 mm
139.02 – 155 in.
Wading depth 660-671 mm
25.98 – 26.42 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 3 gears, automatic transmission Cruise-O-Matic
Front suspension Independent coil spring, Transverse stabilizer
Rear suspension Leaf spring
Front brakes Disc
Rear brakes Drum
Power steering Electric Steering
Tires size 215/75 R15; 225/75 R15
Wheel rims size 7J x 15
