Specifications: Ford F-Series F-150 VII SuperCab 5.0 V8 (133 Hp) 4×4 1984, 1985

Ford F-Series F-150 VII SuperCab 5.0 V8 (133 Hp) 4×4 – Full specifications
General information
Brand Ford
Model F-Series F-100/F-150
Generation F-Series F-150 VII SuperCab
Modification (Engine) 5.0 V8 (133 Hp) 4×4
Start of production 1984 year
End of production 1985 year
Powertrain Architecture Internal Combustion engine
Body type Pick-up
Seats 5-6
Doors 2
Performance specs
Fuel Type Petrol (Gasoline)
Engine specs
Power 133 Hp
Power per litre 26.9 Hp/l
Torque 316 Nm
233.07 lb.-ft.
Engine layout Front, Longitudinal
Engine displacement 4949 cm3
302.01 cu. in.
Number of cylinders 8
Engine configuration V-engine
Fuel injection system Carburettor
Engine aspiration Naturally aspirated engine

Space, Volume and weights
Max. weight 2926 kg
6450.73 lbs.
Fuel tank capacity 72 l
19.02 US gal | 15.84 UK gal
Dimensions
Length 5850 mm
230.31 in.
Width 1778 mm
70 in.
Height 1867 mm
73.5 in.
Wheelbase 3937 mm
155 in.
Wading depth 810 mm
31.89 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 3 gears, manual transmission
Front suspension Independent coil spring
Front brakes Disc
Rear brakes Drum
Power steering Electric Steering
Tires size 235/75 R15
Wheel rims size 15
