Specifications: Ford F-Series F-150 XI Regular Cab 4.6 V8 Triton (231 Hp) 4×4 Automatic 2004, 2005, 2006

2004 Ford F-Series F-150 XI Regular Cab - Photo 1

Ford F-Series F-150 XI Regular Cab 4.6 V8 Triton (231 Hp) 4×4 Automatic – Full specifications
General information
Brand Ford
Model F-Series F-100/F-150
Generation F-Series F-150 XI Regular Cab
Modification (Engine) 4.6 V8 Triton (231 Hp) 4×4 Automatic
Start of production 2004 year
End of production 2006 year
Powertrain Architecture Internal Combustion engine
Body type Pick-up
Seats 3
Doors 2
Performance specs
Fuel Type Petrol (Gasoline)
Weight-to-power ratio 9.8 kg/Hp, 101.8 Hp/tonne
Weight-to-torque ratio 5.7 kg/Nm, 174.9 Nm/tonne
Engine specs
Power 231 Hp @ 4750 rpm.
Power per litre 50.2 Hp/l
Torque 397 Nm @ 3500 rpm.
292.81 lb.-ft. @ 3500 rpm.
Engine layout Front, Longitudinal
Engine displacement 4605 cm3
281.01 cu. in.
Number of cylinders 8
Engine configuration V-engine
Cylinder Bore 90.17 mm
3.55 in.
Piston Stroke 89.92 mm
3.54 in.
Compression ratio 9.3:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain SOHC
Engine oil capacity 5.7 l
6.02 US qt | 5.02 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 19.4 l
20.5 US qt | 17.07 UK qt

Space, Volume and weights
Kerb Weight 2270-2331 kg
5004.49 – 5138.98 lbs.
Max. weight 3152 kg
6948.97 lbs.
Max load 821-882 kg
1810 – 1944.48 lbs.
Fuel tank capacity 98-135 l
25.89 – 35.66 US gal | 21.56 – 29.7 UK gal
Permitted trailer load with brakes (12%) 3084 kg
6799.06 lbs.
Dimensions
Length 5364-5837 mm
211.18 – 229.8 in.
Width 2004 mm
78.9 in.
Height 1875-1920 mm
73.82 – 75.59 in.
Wheelbase 3200-3670 mm
125.98 – 144.49 in.
Front track 1702 mm
67.01 in.
Rear (Back) track 1702 mm
67.01 in.
Minimum turning circle (turning diameter) 12.7-14.1 m
41.67 – 46.26 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 4 gears, automatic transmission
Front suspension Double wishbone
Rear suspension Leaf spring
Front brakes Ventilated discs, 330 mm
Rear brakes Ventilated discs, 348 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 235/70 R17; 275/65 R18
Wheel rims size 17; 18
