Specifications: Ford Fiesta Active VIII (Mk8) 1.0 EcoBoost (140 Hp) 2018, 2019, 2020

2018 Ford Fiesta Active VIII (Mk8) - Photo 1

Ford Fiesta Active VIII (Mk8) 1.0 EcoBoost (140 Hp) – Full specifications
General information
Brand Ford
Model Fiesta
Generation Fiesta Active VIII (Mk8)
Modification (Engine) 1.0 EcoBoost (140 Hp)
Start of production March, 2018 year
End of production June, 2020 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback, Crossover
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 6.3 l/100 km
37.3 US mpg
44.8 UK mpg
15.9 km/l
Fuel consumption (economy) – extra urban 4.6 l/100 km
51.1 US mpg
61.4 UK mpg
21.7 km/l
Fuel consumption (economy) – combined 5.2 l/100 km
45.2 US mpg
54.3 UK mpg
19.2 km/l
CO2 emissions 119 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 9.4 sec
Acceleration 0 – 62 mph 9.4 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.9 sec
Maximum speed 200 km/h
124.27 mph
Emission standard Euro 6
Weight-to-power ratio 8.3 kg/Hp, 120.1 Hp/tonne
Weight-to-torque ratio 6.5 kg/Nm, 154.4 Nm/tonne
Engine specs
Power 140 Hp @ 6000 rpm.
Power per litre 140.3 Hp/l
Torque 180 Nm @ 1500-5000 rpm.
132.76 lb.-ft. @ 1500-5000 rpm.
Engine layout Front, Transverse
Engine Model/Code YYJE, YYJG
Engine displacement 998 cm3
60.9 cu. in.
Number of cylinders 3
Engine configuration Inline
Cylinder Bore 71.9 mm
2.83 in.
Piston Stroke 82 mm
3.23 in.
Compression ratio 10:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 4.6 l
4.86 US qt | 4.05 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5.6 l
5.92 US qt | 4.93 UK qt

Space, Volume and weights
Kerb Weight 1166 kg
2570.59 lbs.
Max. weight 1685 kg
3714.79 lbs.
Max load 519 kg
1144.2 lbs.
Trunk (boot) space – minimum 311 l
10.98 cu. ft.
Trunk (boot) space – maximum 1093 l
38.6 cu. ft.
Fuel tank capacity 42 l
11.1 US gal | 9.24 UK gal
Max. roof load 50 kg
110.23 lbs.
Permitted trailer load with brakes (12%) 1000 kg
2204.62 lbs.
Permitted trailer load without brakes 620 kg
1366.87 lbs.
Permitted towbar download 65 kg
143.3 lbs.
Dimensions
Length 4068 mm
160.16 in.
Width 1756 mm
69.13 in.
Width with mirrors folded 1783 mm
70.2 in.
Width including mirrors 1941 mm
76.42 in.
Height 1498 mm
58.98 in.
Wheelbase 2493 mm
98.15 in.
Front track 1513 mm
59.57 in.
Rear (Back) track 1476 mm
58.11 in.
Front overhang 857 mm
33.74 in.
Rear overhang 718 mm
28.27 in.
Ride height (ground clearance) 130-152 mm
5.12 – 5.98 in.
Drag coefficient (Cd) 0.33
Minimum turning circle (turning diameter) 10.3 m
33.79 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/45 R17
Wheel rims size 17
