Specifications: Ford Fiesta VII (Mk7) 3 door 1.4 (9692 Hp) LPG 2011, 2012

2009 Ford Fiesta VII (Mk7) 3 door - Photo 1

Ford Fiesta VII (Mk7) 3 door 1.4 (96/92 Hp) LPG – Full specifications
General information
Brand Ford
Model Fiesta
Generation Fiesta VII (Mk7) 3 door
Modification (Engine) 1.4 (96/92 Hp) LPG
Start of production 2011 year
End of production 2012 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 3
Performance specs
Fuel consumption (economy) – urban 7.8 l/100 km
30.2 US mpg
36.2 UK mpg
12.8 km/l
Fuel consumption (economy) – urban (LPG) 9.5 l/100 km
Fuel consumption (economy) – extra urban 4.9 l/100 km
48 US mpg
57.6 UK mpg
20.4 km/l
Fuel consumption (economy) – extra urban (LPG) 5.8 l/100 km
Fuel consumption (economy) – combined 6 l/100 km
39.2 US mpg
47.1 UK mpg
16.7 km/l
Fuel consumption (economy) – combined (LPG) 7.2 l/100 km
CO2 emissions 138 g/km
CO2 emissions (LPG) 114 g/km
Fuel Type Petrol / LPG
Acceleration 0 – 100 km/h 12.2 sec
Acceleration 0 – 62 mph 12.2 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.6 sec
Maximum speed 175 km/h
108.74 mph
Emission standard Euro 5
Weight-to-power ratio 10.8 kg/Hp, 92.2 Hp/tonne
Weight-to-torque ratio 8.1 kg/Nm, 123 Nm/tonne
Engine specs
Power 96 Hp @ 5750 rpm.
Power per litre 69.2 Hp/l
Power (LPG) 92 Hp @ 5500 rpm.
Power per litre (LPG) 66.3 Hp/l
Torque 128 Nm @ 4200 rpm.
94.41 lb.-ft. @ 4200 rpm.
Torque (LPG) 123 Nm @ 4300 rpm.
Engine layout Front, Transverse
Engine Model/Code RTJD
Engine displacement 1388 cm3
84.7 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 77.2 mm
3.04 in.
Piston Stroke 74.3 mm
2.93 in.
Compression ratio 8.5:1
Fuel injection system Direct injection
Engine aspiration Naturally aspirated engine
Engine oil specification Log in to see.Log in to see.

Space, Volume and weights
Kerb Weight 1041 kg
2295.01 lbs.
Max. weight 1490 kg
3284.89 lbs.
Max load 449 kg
989.88 lbs.
Trunk (boot) space – minimum 295 l
10.42 cu. ft.
Trunk (boot) space – maximum 979 l
34.57 cu. ft.
Fuel tank capacity 45 l
11.89 US gal | 9.9 UK gal
Max. roof load 50 kg
110.23 lbs.
Permitted trailer load with brakes (12%) 800 kg
1763.7 lbs.
Permitted trailer load without brakes 520 kg
1146.4 lbs.
Dimensions
Length 3950 mm
155.51 in.
Width 1722 mm
67.8 in.
Width including mirrors 1973 mm
77.68 in.
Height 1481 mm
58.31 in.
Wheelbase 2489 mm
97.99 in.
Front track 1493 mm
58.78 in.
Rear (Back) track 1480 mm
58.27 in.
Minimum turning circle (turning diameter) 10.2 m
33.46 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Coil spring, Torsion
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 195/50 R15
Wheel rims size 6J x 15
