Specifications: Ford Fiesta VII (Mk7, facelift 2013) 3 door 1.6 TDCi (95 Hp) 2013, 2014, 2015

2013 Ford Fiesta VII (Mk7, facelift 2013) 3 door - Photo 1

Ford Fiesta VII (Mk7, facelift 2013) 3 door 1.6 TDCi (95 Hp) – Full specifications
General information
Brand Ford
Model Fiesta
Generation Fiesta VII (Mk7, facelift 2013) 3 door
Modification (Engine) 1.6 TDCi (95 Hp)
Start of production 2013 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 3
Performance specs
Fuel consumption (economy) – urban 4.4 l/100 km
53.5 US mpg
64.2 UK mpg
22.7 km/l
Fuel consumption (economy) – extra urban 3.2 l/100 km
73.5 US mpg
88.3 UK mpg
31.3 km/l
Fuel consumption (economy) – combined 3.6 l/100 km
65.3 US mpg
78.5 UK mpg
27.8 km/l
CO2 emissions 95 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 11.7 sec
Acceleration 0 – 62 mph 11.7 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.1 sec
Maximum speed 175 km/h
108.74 mph
Emission standard Euro 5
Weight-to-power ratio 10.9 kg/Hp, 92 Hp/tonne
Weight-to-torque ratio 5.2 kg/Nm, 193.6 Nm/tonne
Engine specs
Power 95 Hp @ 3800 rpm.
Power per litre 60.9 Hp/l
Torque 200 Nm @ 1750-3000 rpm.
147.51 lb.-ft. @ 1750-3000 rpm.
Engine layout Front, Transverse
Engine Model/Code TZJA, T3DA, T3DB
Engine displacement 1560 cm3
95.2 cu. in.
Number of cylinders 4
Engine configuration Inline
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 3.85 l
4.07 US qt | 3.39 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1033 kg
2277.38 lbs.
Max. weight 1570 kg
3461.26 lbs.
Max load 537 kg
1183.88 lbs.
Trunk (boot) space – minimum 281 l
9.92 cu. ft.
Trunk (boot) space – maximum 965 l
34.08 cu. ft.
Fuel tank capacity 40 l
10.57 US gal | 8.8 UK gal
Permitted trailer load with brakes (8%) 900 kg
1984.16 lbs.
Permitted trailer load with brakes (12%) 750 kg
1653.47 lbs.
Permitted trailer load without brakes 550 kg
1212.54 lbs.
Dimensions
Length 3969 mm
156.26 in.
Width 1722 mm
67.8 in.
Width with mirrors folded 1787 mm
70.35 in.
Width including mirrors 1973 mm
77.68 in.
Height 1495 mm
58.86 in.
Wheelbase 2489 mm
97.99 in.
Minimum turning circle (turning diameter) 10.2 m
33.46 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Coil spring, Torsion
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 175/65 R14; 195/55 R15
Wheel rims size 5.5J x 14; 6J x 15
