Specifications: Ford Fiesta VIII (Mk8) 3 door 1.0 EcoBoost (100 Hp) Start-Stop Automatic 2017, 2018, 2019, 2020

2017 Ford Fiesta VIII (Mk8) 3 door - Photo 1

Ford Fiesta VIII (Mk8) 3 door 1.0 EcoBoost (100 Hp) Start-Stop Automatic – Full specifications
General information
Brand Ford
Model Fiesta
Generation Fiesta VIII (Mk8) 3 door
Modification (Engine) 1.0 EcoBoost (100 Hp) Start-Stop Automatic
Start of production July, 2017 year
End of production May, 2020 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 3
Performance specs
Fuel consumption (economy) – urban 6.9 l/100 km
34.1 US mpg
40.9 UK mpg
14.5 km/l
Fuel consumption (economy) – extra urban 4.2 l/100 km
56 US mpg
67.3 UK mpg
23.8 km/l
Fuel consumption (economy) – combined 5.2 l/100 km
45.2 US mpg
54.3 UK mpg
19.2 km/l
CO2 emissions 118 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 12.2 sec
Acceleration 0 – 62 mph 12.2 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.6 sec
Maximum speed 180 km/h
111.85 mph
Emission standard Euro 6
Weight-to-power ratio 11.1 kg/Hp, 90.2 Hp/tonne
Weight-to-torque ratio 6.5 kg/Nm, 153.3 Nm/tonne
Engine specs
Power 100 Hp @ 4500-6500 rpm.
Power per litre 100.2 Hp/l
Torque 170 Nm @ 1500-4000 rpm.
125.39 lb.-ft. @ 1500-4000 rpm.
Engine layout Front, Transverse
Engine Model/Code SFJE, SFJF, SFJH, SFJJ, SFJK, SFJN, SFJP
Engine displacement 998 cm3
60.9 cu. in.
Number of cylinders 3
Engine configuration Inline
Cylinder Bore 71.9 mm
2.83 in.
Piston Stroke 82 mm
3.23 in.
Compression ratio 10:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC, Ti-VCT
Engine oil capacity 4.6 l
4.86 US qt | 4.05 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5.8 l
6.13 US qt | 5.1 UK qt
Engine systems Start & Stop System

Space, Volume and weights
Kerb Weight 1109-1184 kg
2444.93 – 2610.27 lbs.
Max. weight 1635-1650 kg
3604.56 – 3637.63 lbs.
Max load 466-526 kg
1027.35 – 1159.63 lbs.
Trunk (boot) space – minimum 292 l
10.31 cu. ft.
Trunk (boot) space – maximum 1093 l
38.6 cu. ft.
Fuel tank capacity 42 l
11.1 US gal | 9.24 UK gal
Max. roof load 50 kg
110.23 lbs.
Permitted trailer load with brakes (12%) 1000 kg
2204.62 lbs.
Permitted trailer load without brakes 590 kg
1300.73 lbs.
Permitted towbar download 45 kg
99.21 lbs.
Dimensions
Length 4040-4065 mm
159.06 – 160.04 in.
Width 1735 mm
68.31 in.
Width with mirrors folded 1783 mm
70.2 in.
Width including mirrors 1941 mm
76.42 in.
Height 1466-1476 mm
57.72 – 58.11 in.
Wheelbase 2493 mm
98.15 in.
Drag coefficient (Cd) 0.30
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Semi-independent, coil spring, Elastic beam
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 195/60 R15; 195/55 R16; 205/45 R17; 205/40 R18
Wheel rims size 6J x 15; 6.5J x 16; 7J x 17; 7J x 18
